JVC AV-21F3 User Manual

No. 52024
A
V-21F
3
A
V-21FR3
A
V-21FMG3B
27
DEFLECTION CIRCUIT ADJUSTMENT
"
The re are 2 mod es of adju stment (s ettin g va lue) ---- --
①
50 Hz mod e an d
②
6 0Hz mod e - -- - - de pe ndin g u po n th e kind of s igna ls
(vertic al freq ue ncy 50Hz / 60Hz).
"
When ad juste d in mod e ① , mode ② will be automatically set.
The setting (adjustmen t) usin g the REMOTE CONTROL UNIT is made on the basis of the initial setting values.
The setting values which adjust the screen to the optimum condition can be different fr om the initial setting values.
Item
Measuring
instrument
Test point Ad justment part Description
Ad just ment
of V.HEIG HT
&
V. POSITI ON
Signal
generator
Remote
control unit
1. VE R. POSITION
3. VE R. HE IG HT
1. Inp ut a circle p att ern sign al.
2. En ter th e SERVICE ME NU.
3. Select 3. DEF. f rom S ERVICE MENU.
4. Select 1. VER. POS ITION with the MENU
▼
/
▲
key.
5. Set the initial setting value with the MENU - / + key.
6. Adjust V and V’ t o be equal with the MENU - / + key a s shown in
Fig.2.
7. Inp ut a cr oss -hatch sign al.
8. Select 3. V. HEIG HT with the MENU
▼
/
▲
key.
9. Set the initial setting value with the MENU - / + key.
10. As shown in Fig.1, adjust VE R. HE IGH T and mak e th e ver tical
screen size 92% of the pictu re size with t he MENU - / + ke ys of
remote control unit.
Ad just ment
of HOR .
POSITION
Signal
generator
Remote
control unit
2.HOR. POSITION 11. Input a circle pattern signal.
12. Sele ct 2. HOR POSITION with the MENU
▼
/
▲
key.
13 . Se t th e initia l sett ing value of 2. HOR. POSITION with the
MENU - / + key.
14. Adju st 2. HOR. POSITION to make H= H " as sh own in Fig. 2
with the MENU - / + ke y.
Screen size
Picture size 1 00%
Screen
size
92%
size
10 0%
Fig.1
HH"
Fi
g
.2
V
V'
DEF
- / + : OPERATE DISP : EXIT
***
SU B M E NU 3. D EF
/ :SELECT
50Hz
1. VER. POSITI ON
PAL
