JVC AV-21F3 User Manual

No. 52024
A
V-21F3
A
V-21FR3
A
V-21FMG3B
36
EXPLODED VIEW PARTS LIST
! Ref.No. Part No. Part Name Description
! V01 A51KQK99X PICTURE TUBE
! L01 QQW0077-001 DEG COIL or QQW0076-001
!
DY01 QQD0061-001 DEF YOKE
!
T1522 QQH0134-001 F B T
! 1 L C1 03 94 -0 3 8A -H FRO NT CA BI NE T
2 CM48006-007-C JVC MARK
! 3 LC30617-001C-H E.E.WINDOW
!
4 LC30616-004A-H POWER KNOB
5 CM35235-006-H SPRING
! 6 LC20292-004A-H CONTROL KNOB
! 7 LC30618-001B-H LED LENS
8 A48457-3-H SPRING
9 CHGB0016-0B-FH BRAIDED WIRE
10 A75034-B P C MAGNET or CE42378-00B
11 CE42764-00A WEDGE ASSY (X3)
! 12 CM36623-B01-H CHASSIS RAIL (X2)
13 QAS0036-001 SPEAKER (X2)SP01
!
14 QMPR340-165-K2 POWER CORD
!
15 CM47005-A01-H CORD CLAMP
!
16 LC10448-002B-H REAR COVER
! 17 LC20377-010B-H RATING LABEL
18 QYSBSF3010Z TAP SCREW (X1)For REAR COVER
19 QYSBSFG4016Z TAP SCREW (X6)For REAR COVER
!
V01 A51KQK99X PICTURE TUBE
! L01 QQW0077-001 DEG COIL or QQW0076-001
! DY01 QQD0061-001 DEF YOKE
! T1522 QQH0134-001 F B T
!
1 L C1 03 9 4- 03 7A -H FRO NT CA BI NE T
2 CM48006-007-C JVC MARK
! 3 LC30617-001C-H E.E.WINDOW
! 4 LC30616-004A-H POWER KNOB
5 CM35235-006-H SPRING
!
6 LC20292-004A-H CONTROL KNOB
!
7 LC30618-001B-H LED LENS
8 A48457-3-H SPRING
9 CHGB0016-0B-FH BRAIDED WIRE
10 A75034-B P C MAGNET or CE42378-00B
11 CE42764-00A WEDGE ASSY (X3)
!
12 CM36623-B01-H CHASSIS RAIL (X2)
13 QAS0036-001 SPEAKER (X2)SP01
! 14 QMPR340-165-K2 POWER CORD
! 15 CM47005-A01-H CORD CLAMP
!
16 LC10448-002B-H REAR COVER
!
17 LC20377-001B-H RATING LABEL
18 QYSBSF3010Z TAP SCREW (X1)For REAR COVER
19 QYSBSFG4016Z TAP SCREW (X6)For REAR COVER
! V01 A51KQK99X PICTURE TUBE
! L01 QQW0077-001 DEG COIL or QQW0076-001
!
DY01 QQD0061-001 DEF YOKE
!
T1522 QQH0131-001 F B T
! 1 L C1 03 9 4- 03 9A -H FRO NT CA BI NE T
2 CM48006-007-C JVC MARK
! 3 LC30617-001C-H E.E.WINDOW
!
4 LC30616-004A-H POWER KNOB
5 CM35235-006-H SPRING
! 6 LC20292-004A-H CONTROL KNOB
! 7 LC30618-001B-H LED LENS
8 A48457-3-H SPRING
9 CHGB0016-0B-FH BRAIDED WIRE
10 A75034-B P C MAGNET or CE42378-00B
11 CE42764-00A WEDGE ASSY (X3)
! 12 CM36623-B01-H CHASSIS RAIL (X2)
13 QAS0036-001 SPEAKER (X2)SP01
!
14 QMPR340-165-K2 POWER CORD
!
15 CM47005-A01-H CORD CLAMP
!
16 LC10448-002B-H REAR COVER
! 17 LC20377-010B-H RATING LABEL
18 QYSBSF3010Z TAP SCREW (X1)For REAR COVER
19 QYSBSFG4016Z TAP SCREW (X6)For REAR COVER
AV -2 1F 3
AV -2 1F R3
AV-21F MG3B
