1) Connect the cable wire out from
the wall in to the cable box RF
input.
2) Connect an RF cable out from
the cable box, in to VCR RF
input.
3) Connect an RF cable o u t f ro m
V C R RF output, i n to TV VHF/UHF
i n p u t .
4) Plug the power cord into a nearby
A C o u t l e t
❒ Refer to the VCR and/or cable
box instructions.
If you do not re q u i re a cable box to access any or all channels, refer to the Quick Setup Guide.
If you use a cable box to access any or all channels, use the diagram below.
CABLE BOX CONNECTION
Illustration of AV-27020
AV-20020 • AV-20021
AV-27015 AV-27020
C-13010 • C-13011
C-20010
6 C O N N E C T I O N S
REAR PANEL DIAGRAMS
CABLE
BOX
VCR
CABLE or
ANTENNA OUT
To Next Page
