JVC Everio GZ-MS230 User Manual

Backing Up All Files
Before making backup, make sure that
there is enough free space in the PC's
HDD.
1
Connect the USB cable and AC
adapter.
.
USB Cable
(Provided)
AC Adapter
To USB Terminal
To DC Terminal
To USB Terminal
2
Open the LCD monitor.
3
Select “BACK UP” and touch .
.
?
75$/'07
%4'#6'&8&
&+4'%6&8&
72.1#&
':214661.+$4#4;
$#%-72
5'6 37+6
●
The provided software Everio
MediaBrowser starts up on the PC.
The subsequent operations are to be
performed on the PC.
4
Select the volume.
.
2
1
Click
Click
5
Start backup.
.
Click
Saving destination (PC)
6
After backup is complete, click “OK”.
If you encounter any problems with
the provided software Everio
MediaBrowser, please consult the
"Pixela User Support Center".
■
To disconnect this unit from the PC
① Click “Safely Remove Hardware”.
.
② Click “Safely Remove USB Mass
Storage Device”.
③ (For Windows Vista) Click “OK”.
④ Disconnect the USB cable and
close the LCD monitor.
20
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

JVC Everio GZ-MS230 Specifications

General

Digital zoom	800 x
Optical zoom	39 x
Image stabilizer	Yes
Focal length range	2.2 - 85.8 mm
Interchangeable lens	-
Focal length (35mm film equivalent)	38 - 1482 mm
Sensor type	CCD
Total megapixels	- MP
Optical sensor size	1/6 \
Optical sensor resolution	800000 pixels
Interface	USB 2.0
Aperture range (F-F)	1.8 - 4.3
Power consumption (typical)	1.5 W
Display diagonal	2.7 \
Image formats supported	JPG
Maximum image resolution	- pixels
Audio system	Dolby Digital
USB 2.0 ports quantity	1
Flash memory	8 GB
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SD, SDHC
Internal storage capacity	- GB
Product color	Red
Battery type	BN-VG107
Battery capacity	- mAh
Battery life (max)	- h
Camcorder type	Handheld camcorder

Weight and Dimensions

Depth	110 mm
Width	52 mm
Height	62 mm
Weight	230 g
