JVC EX-A10 Service Manual

3-19
Digital amplifier board
Block No. [0][2]
K7301 QQR0621-001Z FERRATE BEADS
K7501 NQR0022-005X FERRITE BEADS
TH201 NAD0025-333X N THERMISTOR 33k Ω
WC201 QZW0112-002 WIRE CLAMP
WC202 QZW0112-002 WIRE CLAMP
X7401 QAX0416-001Z C RESONATOR 8.000MHz
X7411 QAX0401-001 CRYSTAL 32.768KHz
 Symbol No. Part No. Part Name Description Local
IC150 JCV8015-X IC
 IC151 STA506A-W IC
IC152 TC7W04FK-X IC
IC153 TC7W04FK-X IC
IC160 JCV8015-X IC
 IC161 STA506A-W IC
IC162 TC7W04FK-X IC
IC163 TC7W04FK-X IC
IC171 SN74HCU04ANS-X IC
IC172 SN74LV00ANS-X IC
 IC173 NJM78L05A-T IC
Q1101 2SC3661-X TRANSISTOR
Q1171 UN211E-X DIGI TRANSISTOR
Q1172 UN211E-X DIGI TRANSISTOR
Q1201 2SC3661-X TRANSISTOR
Q1271 UN211E-X DIGI TRANSISTOR
Q1272 UN211E-X DIGI TRANSISTOR
Q1301 2SC3661-X TRANSISTOR
Q1371 UN211E-X DIGI TRANSISTOR
Q1372 UN211E-X DIGI TRANSISTOR
Q1401 2SC3661-X TRANSISTOR
Q1471 UN211E-X DIGI TRANSISTOR
Q1472 UN211E-X DIGI TRANSISTOR
Q1701 UN211E-X DIGI TRANSISTOR
 Q1711 KTA1267/YG/-T TRANSISTOR
Q1712 KTC3875/YG/-X SI TRANSISTOR
Q1713 KTC3875/YG/-X SI TRANSISTOR
Q1714 KTC3875/YG/-X SI TRANSISTOR
Q1715 2SB709A/R/-X TRANSISTOR
D1101 MA152WK-X SI DIODE
D1201 MA152WK-X SI DIODE
D1501 UDZS6.8B-X Z DIODE
D1502 1SS355-X SI DIODE
D1571 MA152WK-X SI DIODE
D1601 UDZS6.8B-X Z DIODE
C1101 QTE1V06-106Z E CAPACITOR 10uF 35V
C1102 NCB31HK-221X C CAPACITOR 220pF 50V K
C1111 QTE1C06-476Z E CAPACITOR 47uF 16V
C1112 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1113 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1115 NCB31HK-471X C CAPACITOR 470pF 50V K
C1116 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1121 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C1131 NCB31HK-272X C CAPACITOR 2700pF 50V K
C1136 NCB31CK-105X C CAPACITOR 1uF 16V K
C1141 NCB31CK-105X C CAPACITOR 1uF 16V K
C1143 NDC31HG-101X C CAPACITOR 100pF 50V G
C1151 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1152 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1161 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1162 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1163 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1164 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1165 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1166 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1169 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1170 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1171 NCB21HK-104X C CAPACITOR 0.1uF 50V K
 Symbol No. Part No. Part Name Description Local
C1172 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1173 QFVF1HJ-684Z MF CAPACITOR 0.68uF 50V J
C1175 NCB31HK-471X C CAPACITOR 470pF 50V K
C1176 NCB31HK-471X C CAPACITOR 470pF 50V K
C1177 NCB31CK-105X C CAPACITOR 1uF 16V K
C1178 QEKC1EM-106Z E CAPACITOR 10uF 25V M
C1179 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C1201 QTE1V06-106Z E CAPACITOR 10uF 35V
C1202 NCB31HK-221X C CAPACITOR 220pF 50V K
C1211 QTE1C06-476Z E CAPACITOR 47uF 16V
C1212 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1213 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1215 NCB31HK-471X C CAPACITOR 470pF 50V K
C1216 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1221 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C1231 NCB31HK-272X C CAPACITOR 2700pF 50V K
C1236 NCB31CK-105X C CAPACITOR 1uF 16V K
C1241 NCB31CK-105X C CAPACITOR 1uF 16V K
C1243 NDC31HG-101X C CAPACITOR 100pF 50V G
C1251 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1252 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1261 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1262 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1263 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1264 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1265 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1266 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1269 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1270 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1271 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1272 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1273 QFVF1HJ-684Z MF CAPACITOR 0.68uF 50V J
C1275 NCB31HK-471X C CAPACITOR 470pF 50V K
C1276 NCB31HK-471X C CAPACITOR 470pF 50V K
C1277 NCB31CK-105X C CAPACITOR 1uF 16V K
C1278 QEKC1EM-106Z E CAPACITOR 10uF 25V M
C1279 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C1301 QTE1V06-106Z E CAPACITOR 10uF 35V
C1302 NCB31HK-221X C CAPACITOR 220pF 50V K
C1311 QTE1C06-476Z E CAPACITOR 47uF 16V
C1312 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1313 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1315 NCB31HK-471X C CAPACITOR 470pF 50V K
C1316 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1321 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C1331 NCB31HK-272X C CAPACITOR 2700pF 50V K
C1336 NCB31CK-105X C CAPACITOR 1uF 16V K
C1341 NCB31CK-105X C CAPACITOR 1uF 16V K
C1343 NDC31HG-101X C CAPACITOR 100pF 50V G
C1351 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1352 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1361 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1362 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1363 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1364 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1365 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1366 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1369 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1370 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1371 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1372 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1373 QFVF1HJ-684Z MF CAPACITOR 0.68uF 50V J
C1375 NCB31HK-471X C CAPACITOR 470pF 50V K
C1376 NCB31HK-471X C CAPACITOR 470pF 50V K
C1377 NCB31CK-105X C CAPACITOR 1uF 16V K
C1401 QTE1V06-106Z E CAPACITOR 10uF 35V
C1402 NCB31HK-221X C CAPACITOR 220pF 50V K
C1411 QTE1C06-476Z E CAPACITOR 47uF 16V
C1412 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1413 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1415 NCB31HK-471X C CAPACITOR 470pF 50V K
C1416 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1421 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C1431 NCB31HK-272X C CAPACITOR 2700pF 50V K
C1436 NCB31CK-105X C CAPACITOR 1uF 16V K
C1441 NCB31CK-105X C CAPACITOR 1uF 16V K
C1443 NDC31HG-101X C CAPACITOR 100pF 50V G
C1451 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local

JVC EX-A10 Specifications

General

Impedance	6 Ω
RMS rated power	20 W
Equalizer	Yes
Volume control	Digital
Supported radio bands	AM, FM
Type	Home audio micro system
Speakers	2-Way, Bass-Reflex
Dimensions (WxDxH)	245 x 80 x 297 mm
USB 2.0 ports quantity	1

Weight and Dimensions

Weight	2700 g
Center speaker weight	3500 g
Center speaker dimensions (WxDxH)	143 x 243 x 257 mm
