To Video
Output
Connector cover*
To TV or VCR
To Video
Input
B. Connection to a TV or VCR equipped only with A/V input connectors
Use optional Video and Audio cables.
To Audio
Output
To Audio
Input
A. Connection to a TV or VCR equipped with an S-VIDEO IN and A/V input connectors
(GR-SXM330/SX960 only)
Use optional S-Video and Audio cables.
To S-Video
Input
To S-Video
Output
To TV or VCR
*When connecting the cables, open this cover.
Connector cover*
To Audio
Input
S-Video cable
(optional)
To Audio
Output
TV
VCR
*When connecting the cables, open this cover.
VCR
TV
These are some basic types of connections. When making the connections, refer also to your VCR and TV
instruction manuals.
Audio cable
(optional)
Video cable
(optional)
Audio cable
(optional)
PLAYBACK Connections And Tape Dubbing
