JVC GR-AX760 User Manual

EN45
Controls
1 Video Light Switch [LIGHT OFF/AUTO/ON]
(GR-SXM330/SX960/AXM230 only) .....
Z pg. 17
2 Stop Button [STOP] .............................. Z pg. 30
3 •Retake Rewind Button [RETAKE R] ..... Z pg. 17
•Quick Review Button [
R] ............ Z pg. 17
•Rewind Button [R] .............................
Z pg. 30
4 Play/Pause Button ................................ Z pg. 30
5 •Retake Forward Button [RETAKE F] .... Z pg. 17
•Fast-Forward Button [F] .....................
Z pg. 30
6 •Fade/Wipe Button [FADE/WIPE] ........ Z pg. 19
•Counter Reset/Memory Button
[COUNTER R/M] ..............................
Z pg. 31
7 Program AE Button [P. AE] .................... Z pg. 20
8 Digital Effect Button [DIGIFECT] .......... Z pg. 21
9 NIGHT-ALIVE Button
(GR-SXM330 only)...............................
Z pg. 18
0 REFRESH Button .................................... Z pg. 6
! EJECT Switch ....................................... Z pg. 13
@ Close Button ........................................ Z pg. 13
# •MENU Wheel [–, +] .......................... Z pg. 22
•BRIGHT Wheel [–, +]
(models equipped with
LCD monitor only) ...................... Z pg. 14, 30
•TRACKING Wheel [–, +] ...................
Z pg. 31
$ •Snapshot Button [SNAPSHOT]
(GR-SXM330 only) ............................
Z pg. 18
•5-Second Recording Button [5 SEC. REC]
(GR-SX960/AXM230/AX760 only) .....
Z pg. 17
% •Power Zoom Lever [T/W] .................. Z pg. 16
•Speaker Volume Control [VOL.]
(models equipped with
LCD monitor only) ............................ Z pg. 30
^ •Picture Stabilizer Button
[P. STABILIZER] .................................
Z pg. 16
•Time Base Corrector Button [TBC] .....
Z pg. 31
& Power Switch
[
, OFF, , ] ...................... Z pg. 14, 30
* Recording Start/Stop Button .................. Z pg. 14
( Battery Release Switch
[BATTERY RELEASE] ..............................
Z pg. 6
) Diopter Adjustment Control ................... Z pg. 8
Connectors
The connectors q to r are located beneath the
cover.
q S-Video Output Connector [S]
(GR-SXM330/SX960 only) ....................
Z pg. 32
w Audio Output Connector [A] ................ Z pg. 32
e Video Output Connector [V] ................ Z pg. 32
r DC IN Connector............................... Z pg. 6, 7
Indicators
t CHARGE Lamp ...................................... Z pg. 6
y •Power Lamp ..................................... Z pg. 14
•REFRESH Lamp ...................................
Z pg. 6
Other Parts
u LCD Monitor (models equipped
with LCD monitor only) .................
Z pg. 14, 15
i Shoulder Strap Eyelets ............................ Z pg. 8
o Eyepiece
p Battery Pack Mount ............................... Z pg. 6
Q Viewfinder ............................................. Z pg. 8
W Speaker (models equipped
with LCD monitor only) .......................
Z pg. 30
E •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor
(GR-SXM330 only) ............................
Z pg. 36
R Grip Strap .............................................. Z pg. 8
T Microphone......................................... Z pg. 39
Y Video Light
(GR-SXM330/SX960/AXM230 only) .....
Z pg. 17
U Tripod Mounting Socket ......................... Z pg. 8
