JVC GR-DVF10 Technical Guide

2-16
2. Camera DSP (IC4301: JCY0120) pin functions (1/6)
Pin No. Label In/Out Description
100 VDMDA Out Vertical reference signal output for MDA
158 PWM Out PWM output
20 CLK45 Out 4.5MHz output
1 VSS - Ground for Digital
251 VDDE - Power supply for Digital (I/O)
255 CSYNCI
191 HDANA
117 VDANA
36 ANACNT
33 AY00
113 AY01
186 AY02
32 AY03
35 AC00
34 AC01
187 AC02
114 AC03
188 INHA
115 INVA
138 ADDVSS - Ground for add Digital
256 VDDE - Power supply for Digital (I/O)
64 VSS - Ground for Digital
69 ADDVDDE - Power supply for add Digital (I/O)
137 DSYO0
208 DSYO1
270 DSYO2
61 DSYO3
136 DSYO4
207 DSYO5
60 DSYO6
59 DSYO7
140 DSCO0
210 DSCO1
272 DSCO2
142 DSCO3
139 DSCO4
209 DSCO5
63 DSCO6
62 DSCO7
211 CLKDSC Out Clock for DSC
141 HDDSC Out Horizontal reference pulse output for DSC
212 VDDSC
143 FLDDSC
70 ADDVSS - Ground for add Digital
271 VDDE - Power supply for Digital (I/O)
146 DSYI0
215 DSYI1
145 DSYI2
Not used-
Not used-
Out Vertical reference pulse output for DSC
In Digital luminance signal input for DSC
Table 2-4-1 Camera DSP (IC4301: JCY0120) pin functions (1/6)
