5-10

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

5.6 ELECTRICAL PARTS LIST

MODEL MODELMARK MARK

GR-DVL155EG-X

GR-DVL160EG-X

GR-DVL160EK

GR-DVL167EG-X

GR-DVL167EK

******************************

MAIN BOARD ASSEMBLY <01>

PW YB10359PA-03 MAIN BOARD ASSY,D,E

YB10359PE-03 MAIN BOARD ASSY,A

YB10359PC-03 MAIN BOARD ASSY,B,C

IC1001 UPD703039F1-A25 IC(MICRO C ROM)

or UPD70F3040F1A25 IC(MICRO C ROM)

IC1002 RS5C314 IC

IC1003 X25170S8I-2.5-X IC

or 25LC160-I/SN-X IC

or AT25160N-10SC-X IC

or CAT25C16SI IC

IC1004 TC75S56FU IC

IC1005 TC7S00FU IC

or SN74AHC1G00K IC

IC1006 MB90097PFV145 IC(MICRO C ROM)

IC1007 TC74VHC08FT IC(DIGITAL)

or SN74LV08APW IC

IC1008 IC-PST3423U-X IC

IC1301 SN74LV08APW IC

IC1302 MAX3221CAE IC

or ICL3221CA IC

IC1303 SN74LV02APW IC

IC1401 UPD703040YF-M06 IC(MICRO C ROM),D,E

UPD703040YF-M09 IC(MICRO C ROM),A,B,C

or UPD70F3040YFM09 IC(MICRO C ROM),A,B,C

or UPD70F3040YFM06 IC(MICRO C ROM),D,E

IC1402 TC7W66FU IC(DIGITAL)

or SN74AHC2G66T IC

IC1601 BD6631KV IC

IC1602 TC7W14FU IC(DIGITAL)

or SN74AHC2G14T IC

IC2001 AK4560AVQ IC

IC3001 JCY0152 IC

IC3005 JCY0136 IC

IC3501 JCY0132 IC

IC3502 SN74AHC1G04K IC

IC3701 BA7665FS IC

IC4201 HD49334F IC

IC4202 MM1385HN IC

IC4301 JCY0150 IC

IC4302 TMS4C2973-28-X IC

IC4802 TA75W01FU IC

IC4803 TA75W01FU IC

IC4804 LM358DR2 IC

IC4851 UPD16879GS IC

IC5501 JCY0117 IC

IC6001 S-80842ANNP-W IC

or S-80842CNNB-W IC

IC6101 FA3698F IC

Q1001 DTC124EE DIGI TRANSISTOR

or UN9212J DIGI TRANSISTOR

Q1002 2SC4617/QR/-X TRANSISTOR

or 2SD2216J/QR/-X TRANSISTOR

Q1003 DTC143EE DIGI TRANSISTOR

or UN921LJ DIGI TRANSISTOR

Q1005 2SJ347 MOS FET

Q1006 DTA114EE DIGI TRANSISTOR

or PDTA114EE DIGI TRANSISTOR

or UN9111J DIGI TRANSISTOR

Q1007 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q1008 DTA114EE DIGI TRANSISTOR

or PDTA114EE DIGI TRANSISTOR

or UN9111J DIGI TRANSISTOR

Q1009 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q1301 2SC4617/QR/-X TRANSISTOR

or 2SD2216J/QR/-X TRANSISTOR

Q1401 DTA114EE DIGI TRANSISTOR

or PDTA114EE DIGI TRANSISTOR

or RN2102 DIGI TRANSISTOR

or UN9111J DIGI TRANSISTOR

Q1402 UMC3N DIGI TRANSISTOR

Q1403 UMC3N DIGI TRANSISTOR

Q1601 UMC3N DIGI TRANSISTOR

Q2001 UMX1N PAIR TRANSISTOR

Q2002 2SC4617/RS/-X TRANSISTOR

or 2SD2216J/RS/-X TRANSISTOR,B,C,D,E

Q3001 2SC4617/RS/-X TRANSISTOR

Q3002 2SC4617/RS/-X TRANSISTOR

Q3701 UMT2N PAIR TRANSISTOR

or XP6401 TRANSISTOR

Q3702 UMZ1N PAIR TRANSISTOR

or XP4601 TRANSISTOR

Q4301 UMT2N PAIR TRANSISTOR

or XP6401 TRANSISTOR

Q4302 UMT2N PAIR TRANSISTOR

or XP6401 TRANSISTOR

Q4801 2SC4655/BC/-X TRANSISTOR

Q4806 2SC4617/QR/-X TRANSISTOR

Q4851 2SC4617/RS/-X TRANSISTOR

Q6001 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or RN1104 DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q6002 MCH6613 MOS FET

Q6004 2SB1188/QR/-W TRANSISTOR

Q6201 MCH3308 MOS FET

Q6202 2SA1577/RS/-X TRANSISTOR

Q6203 MCH3308 MOS FET

Q6204 CPH3314 MOS FET

Q6205 CPH3101 TRANSISTOR

Q6206 2SC4617/RS/-X TRANSISTOR

Q6207 2SD2444K TRANSISTOR,B,C,D,E

Q6208 MCH3308 MOS FET

Q6210 MCH3308 MOS FET

Q6211 MCH3308 MOS FET

Q6212 HN1C01FU/G/-X PAIR TRANSISTOR

or PUMX1 PAIR TRANSISTOR

or UMX1N PAIR TRANSISTOR

Q6213 2SA1577/RS/-X TRANSISTOR

Q6214 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or RN1104 DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q6215 HN1A01FU/G/-X PAIR TRANSISTOR

or PUMT1 PAIR TRANSISTOR

or UMT1N PAIR TRANSISTOR

Q6216 2SC4617/RS/-X TRANSISTOR

Q6217 UMZ1N PAIR TRANSISTOR,B,C,D,E

Q6701 CPH3314 MOS FET
