JVC GR-DVL910A User Manual

EN79
Controls
1 Monitor Open Button
[PUSH OPEN] .....................................  pg. 16
2 Dioptre Adjustment Control .................  pg. 10
3 Battery Release Switch
[BAT. RELEASE] ......................................  pg. 8
4 •MENU Wheel [+, –, PUSH] ...............  pg. 46
•LCD Monitor BRIGHT
(Brightness) Control [+, –] ..................  pg. 16
5 Snapshot Button
[SNAPSHOT] ................  pg. 26, 27, 42, 55, 56
6 •Power Zoom Lever [T/W] ..................  pg. 18
•Speaker Volume Control [VOL.] ........  pg. 21
7 •FOCUS Button ..................................  pg. 43
•BLANK SEARCH Button ....................  pg. 24
•JUMP Button (GR-DVL910A/DVL510A/
DVL910EA/DVL510EA only) .............  pg. 30
8 •Stop Button [5] .................................  pg. 21
•NIGHT-SCOPE Button .......................  pg. 38
9 •Rewind Button [
2 ] .........................  pg. 21
•EXPOSURE Button ............................  pg. 44
0 •Play/Pause Button [
4 /6] ...................  pg. 21
•Programme AE Button [P.AE] .............  pg. 38
! •Fast-Forward Button [
3 ] .................  pg. 21
•BACKLIGHT Button ..........................  pg. 44
@ Power Switch
[
, , , OFF] ...........................  pg. 17
# Recording Start/Stop Button ..................  pg. 16
$ Lock Button .........................................  pg. 17
% Video Light Switch
[LIGHT OFF/AUTO/ON] ......................  pg. 19
^ VIDEO/DSC Switch [VIDEO,
]
(GR-DVL910A/DVL510A/DVL910EA/
DVL510EA only) ..................................  pg. 17
& OPEN/EJECT Switch .............................  pg. 12
Connectors
The connectors * to q are located beneath a cover.
* S-Video Input (GR-DVL910A/DVL510A/
DVL910EA/DVL510EA only)/
Output Connector [S] ........  pg. 22, 52, 53, 62
( •PC (DIGITAL PHOTO) Connector
(GR-DVL450A/DVL313A/DVL310A/
DVL210A/DVL210EA only) ...............  pg. 68
•USB (Universal Serial Bus) Connector
(GR-DVL910A/DVL510A/DVL910EA/
DVL510EA only) ...............................  pg. 68
Connect to a USB-equipped computer to
download the entire contents of a memory card
in only 80 seconds using the provided software.
) •J Terminal [JLIP (Joint Level Interface Protocol)]
(GR-DVL450A/DVL313A/DVL310A/
DVL210A/DVL210EA only) ...............  pg. 62
Connect to a JLIP-compatible camcorder or VCR
to control it from the computer using the
Software.
Connect the editing cable when performing
Random Assemble Editing .........  pg. 61 – 65
•Edit Connector [EDIT] (GR-DVL910A/
DVL510A/DVL910EA/DVL510EA
only) .................................................  pg. 62
q Audio/Video Input (GR-DVL910A/DVL510A/
DVL910EA/DVL510EA only)/
Output Connector [AV] .....  pg. 22, 52, 53, 62
w DC Input Connector ..........................  pg. 8, 9
e Digital Video Connector [DV IN/OUT]
(i.Link*) ...................................  pg. 54, 68, 69
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The
logo
is used for products compliant with the i.Link
standard.
Indicators
r Tally Lamp .....................................  pg. 16, 48
t Side LED Indicator (GR-DVL910A/
DVL450A/DVL910EA only) ..................  pg. 49
y CHARGE Lamp ......................................  pg. 8
u Power Lamp ..................................  pg. 16, 17
Other Parts
i •Remote Sensor ..................................  pg. 57
•Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
o Viewfinder ...........................................  pg. 10
p Video Light ..........................................  pg. 19
Q Stereo Microphone ..............................  pg. 66
W Shoulder Strap Eyelets ..........................  pg. 10
E Grip Strap ............................................  pg. 10
R Viewfinder Cleaning Hatch ..................  pg. 77
T Battery Pack Mount ...............................  pg. 8
Y LCD Monitor .................................  pg. 16, 17
U Speaker ...............................................  pg. 21
I Stud Hole ............................................  pg. 10
O Tripod Mounting Socket .......................  pg. 10
P MEMORY CARD Cover
(GR-DVL910A/DVL510A/DVL910EA/
DVL510EA only) ..................................  pg. 14
