EN 17
PAUSE
OFF
P
L
A
Y
A
M
5S
Diopter Adjustment
Adjust the viewfinder display for best viewing.
1
SELECT OPERATION MODE
Set the Power Dial to “
A
” or “
M
”.
2
TURN ON CAMCORDER
Pull out the viewfinder fully.
3
ADJUST DIOPTER
Slide the Diopter Adjust Lever located on the
bottom of the viewfinder.
•Slide in either direction, while looking at the
viewfinder display, until it looks best to you.
Diopter
adjust lever
Tripod Mounting
Align the tripod’s screw with the mounting socket
on the bottom of the camcorder.
NOTE:
If the LCD monitor is opened with the viewfinder
pulled out, no image will appear on the LCD
monitor. Push the viewfinder back in.
Bottom of
camcorder
