EN87
Controls
1 PRINT Button
Enables printing using the optional printer
equipped with a PRINT DATA connector. Refer to
the separate “FOR OWNERS OF AN OPTIONAL
PRINTER” instruction sheet.
2 PRINT FRAME Button .......................... pg. 53
3 E-MAIL CLIP REC Button ...................... pg. 46
4 START/STOP Button ............................. pg. 18
5 Power Zoom Lever [T/W] .................. pg. 22
Speaker/Headphone Volume Control
[VOL.] .............................................. pg. 42
6 MENU Wheel [+, –,
4
] ..................... pg. 28
LCD Monitor Brightness
Control [+, –] .................................... pg. 18
7 Snapshot Button
[SNAPSHOT] ................ pg. 20, 21, 24, 26, 65
8 INDEX Button .......................... pg. 39, 48, 49
9 IMAGE SIZE/RES. Button ...................... pg. 15
0 DIGITAL SOUND Button ............... pg. 39, 77
! Battery Release Switch
[BATT. RELEASE] .................................... pg. 9
@ OPEN/EJECT Switch ............................. pg. 12
# Play/Pause Button [
4
/6] ................... pg. 42
EXPOSURE Button ............................ pg. 40
$ Rewind Button [
2
] ......................... pg. 42
BACKLIGHT Button .......................... pg. 40
% Stop Button [5] ................................... pg. 42
^ Fast-Forward Button [
3
] ................. pg. 42
FOCUS Button .................................. pg. 27
& Operation Switch [ , ] .................. pg. 16
* POWER Switch
[ , ,
M
E
M
O
R
Y
P
L
A
Y
, OFF] ............ pg. 16
( Lock Button ......................................... pg. 16
) MODE Dial
[ , VIDEO,
DUAL
, ] .................. pg. 17
q Diopter Adjustment Control ................. pg. 10
Connectors
The connectors
w
to
r
are located beneath a cover.
w Digital Video Connector [DV IN/OUT]
(i.link*) .................................... pg. 60, 61, 63
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
e Audio/Video Output Connector
[AV OUT] ......................................... pg. 58
• Headphone Connector [ ] .............. pg. 76
r Multi Connector
When attached to the Docking Station, this part is
connected.
Indicators
t Tally Lamp ........................................... pg. 18
y POWER Lamp ..................................... pg. 18
Other Parts
u LCD Monitor ................................. pg. 18, 19
i Battery Pack Mount ............................... pg. 9
o Speaker ............................................... pg. 42
p Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
Q Stereo Microphone .............................. pg. 76
W Flash Sensor
Be careful not to cover this area, as it contains a
sensor required by the flash.
E Flash ................................................... pg. 32
R Lens
T Lens Protector
When using an optional lens filter (commercially
available), you must first detach the lens cover.
Y Remote Sensor ..................................... pg. 66
U Grip Strap ............................................ pg. 10
I Viewfinder ........................................... pg. 10
O Viewfinder Cleaning Hatch .................. pg. 78
P Memory Card Cover ............................ pg. 14
a Cassette Holder Cover ......................... pg. 12
s Tripod Mounting Socket ....................... pg. 10
d Stud Hole ............................................ pg. 58
