JVC GR-FXM37 User Manual

36 EN
1
1
2
3
1
2
3
1
A
B
Installing The Battery
(RM-V700U, optional)
The remote control uses one lithium battery
(CR2025).
1
: Pull out the battery holder while sliding the
lock hole.
: Pinch the release tab and pull out the
battery holder.
2
Insert the battery in the holder, and be sure to
have the “+” mark visible.
3
Slide the holder back in until you hear a click.
•Read the cautions in the instructions provided
with the RM-V700U.
Installing The Batteries
(RM-V715U, provided)
The remote control uses two ”AAA (R03)” size
batteries. See “General Battery Precautions”
(墌 pg. 45).
1
Open the battery compartment cover as
illustrated.
2
Insert two ”AAA (R03)” size batteries in the
correct direction.
3
Replace the battery compartment cover.
When using the remote control, be sure to point it
at the remote sensor. The illustration shows the
approximate transmitted beam effective area for
indoor use.
The transmitted beam may not be effective or may
cause incorrect operation outdoors or when the
remote sensor is directly exposed to sunlight or
powerful lighting.
Transmitted beam
effective area
Remote sensor
Lock hole
Knob
1
1
2
2
3
3
USING THE REMOTE CONTROL UNIT (GR-SXM607 only) (cont.)
