EN43
Controls
1 Video Light Switch [LIGHT OFF/AUTO/ON]
(GR-SXM47/SX22 only) ....................... 墌 pg. 18
2 Stop Button [STOP] .............................. 墌 pg. 30
3 •Retake Rewind Button [RETAKE R] ..... 墌 pg. 17
•Quick Review Button [ R] ............ 墌 pg. 17
•Rewind Button [R] ............................. 墌 pg. 30
4 Play/Pause Button ................................ 墌 pg. 30
5 •Retake Forward Button [RETAKE F] .... 墌 pg. 17
•Fast-Forward Button [F] ..................... 墌 pg. 30
6 •Fade/Wipe Button [FADE/WIPE] ........ 墌 pg. 19
•Counter Reset/Memory Button
[COUNTER R/M] .............................. 墌 pg. 31
7 Program AE Button [P. AE] .................... 墌 pg. 20
8 Digital Effect Button [DIGIFECT] .......... 墌 pg. 21
9 REFRESH Button .................................... 墌 pg. 6
0 EJECT Switch ....................................... 墌 pg. 13
! Close Button ........................................ 墌 pg. 13
@ •MENU Wheel [–, +] .......................... 墌 pg. 22
•BRIGHT Wheel [–, +]
(models equipped with
LCD monitor only) ...................... 墌 pg. 14, 30
•TRACKING Wheel [–, +] ................... 墌 pg. 31
# 5-Second Recording Button
[5 SEC. REC] ....................................... 墌 pg. 17
$ •Power Zoom Lever [T/W] .................. 墌 pg. 16
•Speaker Volume Control [VOL.]
(models equipped with
LCD monitor only) ............................ 墌 pg. 30
% •Picture Stabiliser Button
[P. STABILIZER] ................................. 墌 pg. 16
•Time Base Corrector Button [TBC] ..... 墌 pg. 31
^ Power Switch
[ , OFF, , ] ...................... 墌 pg. 14, 30
& Recording Start/Stop Button .................. 墌 pg. 14
* Battery Release Switch
[BATTERY RELEASE] .............................. 墌 pg. 6
( Dioptre Adjustment Control ................... 墌 pg. 8
Connectors
The connectors ) to r are located beneath the
cover.
) S-Video Output Connector [S]
(GR-SXM47/SX22 only) ........................ 墌 pg. 32
q Audio Output Connector [A] ................ 墌 pg. 32
w Video Output Connector [V] ................ 墌 pg. 32
e J Terminal/Edit Connector
[JLIP (Joint Level Interface Protocol)/EDIT]
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
r DC IN Connector ............................... 墌 pg. 6, 7
Indicators
t CHARGE Lamp ...................................... 墌 pg. 6
y •Power Lamp ..................................... 墌 pg. 14
•REFRESH Lamp ................................... 墌 pg. 6
Other Parts
u LCD Monitor (models equipped with
LCD monitor only) ......................... 墌 pg. 14, 15
i Shoulder Strap Eyelets ............................ 墌 pg. 8
o Eyepiece
p Battery Pack Mount ............................... 墌 pg. 6
Q Viewfinder ............................................. 墌 pg. 8
W Speaker (models equipped with
LCD monitor only) ............................... 墌 pg. 30
E Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
R Grip Strap .............................................. 墌 pg. 8
T Microphone
Y Video Light (GR-SXM47/SX22 only) ..... 墌 pg. 18
U Tripod Mounting Socket ......................... 墌 pg. 8
To Next Page
