A/V Set Menu
Menu screen for video output and audio.
Video Set...
For specifying video output-related settings.
(A P112 [Video Set Item] )
Audio Set...
For specifying audio-related settings.
(A P113 [Audio Set Item] )
Video Set Item
Display On TV
For setting
whether to display the display and menu
characters on the external monitor.
[Setting Values: On, ROff]
HDMI/SDI Out
For setting the terminal to output the video.
[Setting Values: HDMI+SDI, SDI, HDMI, ROff]
Memo :
0
When the [Network] setting is set to
“On(SDI
Off)”, “HDMI+SDI” and “SDI” are not selectable.
And when “On(HDMI Off)” is set, “HDMI+SDI”
and “HDMI” are not selectable.
9
Resolution
For
selecting
the resolution of video output from the
[HDMI]/[SDI] terminal according to the monitor to
be connected.
[Setting Values: 576i, 576p, 480i, 480p, 720p,
R1080i, 1080p]
Memo :
0
When [Main Menu
] B [A/V Set] B [Video Set] B
[HDMI/SDI Out] is set to “HDMI+SDI” or “SDI”,
“1080p” cannot be selected.
0
When
[Main Menu] B [A/V Set] B [Video Set] B
[HDMI/SDI Out] is set to “HDMI+SDI” or “SDI”,
changing the resolution will cause the camera
recorder to restart. “Please Wait...” will be
displayed.
0
The selectable options vary according to the
setting in [System
]
/[WResolution]/[WFrame &
Bit Rate] of [System] B [Record Set] B [Record
Format].
0
Cross conversion output is not possible.
9
HDMI Color
0
For setting the color format of HDMI signals.
0
This item is selectable only when [HDMI/SDI
Out]
is set to “HDMI” or “HDMI+SDI”.
[Setting Values: RGB, RAuto]
9
HDMI Enhance
0
For setting the color range of HDMI signals.
When connecting to a PC monitor, set this to
“
On
”.
0
This item is selectable only when [HDMI/SDI
Out] is set to “HDMI”
or “HDMI+SDI”.
[Setting Values: On, ROff]
9
Rec Trigger
For setting
whether to superimpose trigger signals
in tandem with the [HDMI] terminal, [HD/SD SDI]
terminal and the [REC] button on the camera body.
When a compatible device is connected,
recording/stop control signals are output in tandem
with the operation of the [REC] button.
The record trigger output status to the connected
device is indicated by REC B/STBYB on the
display screen.
0
HDMI+SDI:
Superimposes
the
trigger signals in tandem with
the [HDMI] terminal, [HD/SD SDI] terminal and
the [REC] button on the camera body and
outputs the recording/stop control signals to the
compatible device.
0
SDI:
Superimposes
the
trigger signals in tandem with
the [SDI] terminal as well as the [REC] button on
the camera body and outputs the recording/stop
control signals to the compatible device.
0
HDMI:
Superimposes the
trigger signals in tandem with
the [HDMI] terminal as well as the [REC] button
on the camera body and outputs the recording/
stop control signals to the compatible device.
0
Off:
Does not superimpose the trigger signals.
[Setting Values: ROff, HDMI, SDI, HDMI+SDI]
Memo :
0
Even if REC B/STBYB is displayed on the
display screen, the compatible device may not
necessarily be recording.
0
When [Main Menu
] B [A/V Set] B [Video Set] B
[HDMI/SDI Out] is set to “Off”, [Rec Trigger] is
fixed at “Off” and cannot be selected.
0
When [Main Menu
]
B [System] B [Record Set]
B [Rec Mode] is set to “Interval Rec”, “Frame
Rec” or “Variable Frame”, [Rec Trigger] is fixed
at “Off” and cannot be selected.
0
Set to “Off” if connecting to a device that does
not support record trigger.
112
Menu Display and Detailed Settings
