3-4
General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 GE10043-210A TOP CHASSIS
2 GE40135-001A EARTH PLATE
3 GE30938-003A SIDE PANEL
4 GE30393-002A BOTTOM COVER
5 FSMA3004-203 INSULATOR
6 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
7 FSKZ4005-001 SCREW (x2)
8 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
9 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
10 QYSDST2610Z SCREW 2.6mm x 10mm
11 GE10079-001A FRONT CHASSIS
12 FSYH4036-098 SHEET
13 QYSDST2004M MINI SCREW 2mm x 4mm(x2)
14 GE31033-001A LOCK LEVER
15 FSKW4005-003 TORSION SPRING
16 GE40202-005A
COMPRESSION
SPRING
17 GE31034-001A RLS KNOB
18 GE40156-001A BLIND
19 GE10077-001A FRONT PANEL
20 GE31031-028A FINDER ASSY
21 GE31027-001A POWER BUTTON
22 GE31038-001A VOLUME KNOB
23 GE40218-002A SHEET
24 GE31039-003A SEL BUTTON
25 FSYH4036-053 SHEET
26 GE31040-001A RIM LENS
27 FSYH4036-069 SHEET
28 GE31029-001A D.FUNC BTN
29 FSYH4036-069 SHEET
30 GE20161-001A PRESET BUTTON
31 FSYH4036-069 SHEET (x2)
32 GE31024-001A UP/DOWN BTN
33 GE31028-003A SSM BTN
34 GE31025-001A SEARCH BTN
35 GE31026-001A EJECT BUTTON
36 GE31032-002A DETACH BTN
37 GE40202-003A
COMPRESSION
SPRING
38 GE10078-001A REAR COVER
39 VKZ4777-001 MINI SCREW (x4)
40 GE31021-001A LCD CASE
41 GE31022-002A LCD LENS
42 GE31023-001A LENS CASE
43 GE40199-001A LIGHTING SHEET
44 GE40199-002A LIGHTING SHEET
45 GE31077-002A NAME PLATE
46 LV41843-002A LASER CAUTION
47 QLD0289-001 LCD MODULE
48 QNZ0443-001 LCD CONNECTOR
49 QMFZ047-150-T FUSE 15A
50 GE30912-006A REAR BRACKET
51 QYSDST2606Z SCREW 2.6mm x 6mm
52 QYSDST2606Z SCREW 2.6mm x 6mm
53 QYSDST2606Z SCREW 2.6mm x 6mm
54 QYSDSF2606Z SCREW 2.6mm x 6mm(x2)
55 QYSDSF2606Z SCREW 2.6mm x 6mm
56 GE40172-004A IC BRACKET
57 GE40103-003A REG BRACKET
58 GE40107-002A HEAT SINK
59 GE30854-001A LED HOLDER
