3-9
Front board
Block No. [0][2][0][0]
R554 NRSA02J-513X MG RESISTOR 51k
Ω
1/10W J
R557 NRS181J-332X MG RESISTOR 3.3k
Ω
1/8W J
R558 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R559 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R570 NRSA02J-822X MG RESISTOR 8.2k
Ω
1/10W J
R581 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R582 NRSA63J-822X MG RESISTOR 12k
Ω
1/16W J
R583 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R584 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R585 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R586 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R591 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R592 NRSA63J-822X MG RESISTOR 12k
Ω
1/16W J
R593 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R594 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R595 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R596 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R701 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R703 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R704 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R705 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R706 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R707 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R708 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R709 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R710 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R711 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R712 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R713 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R715 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R716 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R717 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R718 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R720 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R721 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R723 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R724 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R725 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R726 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R727 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R728 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R729 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R730 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R731 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R732 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R733 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R735 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R736 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R737 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R738 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R739 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R740 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R741 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R743 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R745 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R749 NRSA02J-473X MG RESISTOR 47k
Ω
1/10W J
R801 NRSA02J-104X MG RESISTOR 100k
Ω
1/10W J
R802 NRSA02J-104X MG RESISTOR 100k
Ω
1/10W J
R803 NRSA02J-101X MG RESISTOR 100
Ω
1/10W J
R804 NRSA02J-334X MG RESISTOR 330k
Ω
1/10W J
R805 NRSA02J-334X MG RESISTOR 330k
Ω
1/10W J
R806 NRSA02J-104X MG RESISTOR 100k
Ω
1/10W J
R807 NRSA02J-101X MG RESISTOR 100
Ω
1/10W J
R808 NRSA02J-223X MG RESISTOR 22k
Ω
1/10W J
R809 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R810 NRSA02J-104X MG RESISTOR 100k
Ω
1/10W J
R901 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R902 QRE142J-102X C RESISTOR 1k
Ω
1/4W J
R903 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R905 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R906 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
R907 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R908 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R909 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R910 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J
R911 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R912 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
Symbol No.
Part No. Part Name Description Local
L1 QQL244J-4R7Z INDUCTIOR 4.7uH J
L501 QQL244K-4R7Z COIL 4.7uH K
L521 QQL244K-4R7Z COIL 4.7uH K
L522 QQL244K-4R7Z COIL 4.7uH K
L701 QQL244K-4R7Z COIL 4.7uH K
L901 QQR0703-001 CHOKE COIL
CJ1 QNB0190-001 CAR ANT JACK
CJ321 QNN0519-001 SURROUND JACK
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 VMC0334-001 CONNECTOR
CN901 QNZ0611-001 16P CONNECTOR
J801 QNZ0095-001 CONNECTOR
TU1 QAU0311-001 TUNER PACK
X521 QAX0714-001Z C RESONATOR 16.000MHz
X701 QAX0759-001Z CRYSTAL
Symbol No.
Part No. Part Name Description Local
IC661 PT6523LQ IC
IC681 RPM7338-V4 REMOCON RCV
Q670 2SB624/4/-X TRANSISTOR
Q671 UN2211-X TRANSISTOR
D629 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J
D630 SML-310LT/MN/-X LED
D631 SML-310VT/JK/-X LED
D632 SML-310VT/JK/-X LED
D633 SML-310VT/JK/-X LED
D634 SML-310VT/JK/-X LED
D635 SML-310VT/JK/-X LED
D636 SML-310VT/JK/-X LED
D637 SML-310VT/JK/-X LED
D638 SML-310VT/JK/-X LED
D639 SML-310VT/JK/-X LED
D640 SML-310VT/JK/-X LED
D641 SML-310VT/JK/-X LED
D642 SML-310VT/JK/-X LED
D643 SML-310VT/JK/-X LED
D644 LNJ308G81/1-3/X LED
D645 LNJ308G81/1-3/X LED
D646 SML-310VT/JK/-X LED
D647 SML-310VT/JK/-X LED
D648 SML-310VT/JK/-X LED
D649 SML-310VT/JK/-X LED
D650 SML-310VT/JK/-X LED
D651 SML-310VT/JK/-X LED
D652 NSPW310BS/B2RS/ LED
D653 NSPW310BS/B2RS/ LED
D661 MA111-X SI DIODE
D662 UDZS5.1B-X Z DIODE
D681 MA8062/M/-X Z DIODE
C661 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C662 NCS31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C681 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C686 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C687 NCB31HK-223X C CAPACITOR 0.022uF 50V K
R601 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R602 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R603 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R604 NRSA63J-911X MG RESISTOR 910
Ω
1/16W J
R605 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R606 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R607 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R608 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R609 NRSA63J-911X MG RESISTOR 910
Ω
1/16W J
R610 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
