3-7
Electrical parts list
Main board
Block No. [0][1][0][0]

Symbol No.
Part No. Part Name Description Local
IC161 TEA6320T-X IC
IC301 LA47515 IC
IC501 AN22002A-W IC
IC521 MN6627482WA IC
IC561 LA6242H-X IC
IC581 NJM4565M-WE IC
IC701 LC723748-9C23 IC
IC801 HD74HC126FP-X IC
IC901 AN80T07 IC
Q1 UN2211-X TRANSISTOR
Q2 UN2211-X TRANSISTOR
Q4 UN2211-X TRANSISTOR
Q5 2SB1197K/QR/-X TRANSISTOR
Q6 2SB709A/QR/-X TRANSISTOR
Q31 2SD601A/QR/-X TRANSISTOR
Q32 2SD601A/QR/-X TRANSISTOR
Q301 UN2211-X TRANSISTOR
Q341 2SD1781K/QR/-X TRANSISTOR
Q351 2SD1781K/QR/-X TRANSISTOR
Q501 2SA2093/QR/-T TRANSISTOR
Q561 2SA2093/QR/-T TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2111-X TRANSISTOR
Q902 2SD601A/QR/-X TRANSISTOR
Q903 2SB709A/QR/-X TRANSISTOR
D1 1SS355-X SI DIODE
D2 1SS355-X SI DIODE
D3 1SS355-X SI DIODE
D4 1SS355-X SI DIODE
D5 UDZS10B-X Z DIODE
D6 1SS355-X SI DIODE
D8 1SS355-X SI DIODE
D301 1SS355-X SI DIODE
D331 1SS355-X SI DIODE
D341 1SS355-X SI DIODE
D561 1A3G-T1 SI DIODE
D701 1SS355-X SI DIODE
D702 1SS355-X SI DIODE
D706 1SS355-X SI DIODE
D711 UDZS6.2B-X Z DIODE
D712 UDZS6.2B-X Z DIODE
D713 UDZS6.2B-X Z DIODE
D714 UDZS6.2B-X Z DIODE
D715 UDZS6.2B-X Z DIODE
D716 UDZS6.2B-X Z DIODE
D717 UDZS6.2B-X Z DIODE
D718 UDZS6.2B-X Z DIODE
D719 UDZS6.2B-X Z DIODE
D720 UDZS6.2B-X Z DIODE
D781 1SS355-X SI DIODE
D782 UDZS11B-X Z DIODE
D901 1N5401-TU-15 DIODE
D903 1SS355-X SI DIODE
D904 RB160M-30-X SB DIODE
D905 RB160M-30-X SB DIODE
C1 NDC31HJ-221X C CAPACITOR 220pF 50V J
C2 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C3 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C4 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C6 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C8 NDC31HJ-121X C CAPACITOR 120pF 50V J
C9 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C10 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C11 NCB31HK-331X C CAPACITOR 330pF 50V K
C14 NDC31HJ-101X C CAPACITOR 100pF 50V J
C31 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C32 NCB31HK-102X C CAPACITOR 1000pF 50V K
C33 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C81 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C82 NCB31HK-472X C CAPACITOR 3300pF 50V K
C83 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C91 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C92 NCB31HK-472X C CAPACITOR 3300pF 50V K
C93 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C161 NCB31HK-822X C CAPACITOR 8200pF 50V K
C162 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C163 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C164 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C165 NCB31HK-562X C CAPACITOR 5600pF 50V K
C166 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C167 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C168 QFVD1HJ-474Z MF CAPACITOR 0.47uF 50V J
C169 QFVD1HJ-474Z MF CAPACITOR 0.47uF 50V J
C171 NCB31HK-822X C CAPACITOR 8200pF 50V K
C172 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C173 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C174 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C175 NCB31HK-562X C CAPACITOR 5600pF 50V K
C176 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C177 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C178 QFVD1HJ-474Z MF CAPACITOR 0.47uF 50V J
C179 QFVD1HJ-474Z MF CAPACITOR 0.47uF 50V J
C181 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C182 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C183 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C184 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C185 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C191 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C192 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C193 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C194 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C301 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C302 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C303 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C304 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C305 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C306 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C307 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C308 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C309 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C310 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C311 QERF1CM-226Z E CAPACITOR 22uF 16V M
C312 NDC31HJ-101X C CAPACITOR 390pF 50V J
C313 NDC31HJ-101X C CAPACITOR 390pF 50V J
C314 NDC31HJ-101X C CAPACITOR 390pF 50V J
C315 NDC31HJ-101X C CAPACITOR 390pF 50V J
C317 QERF1HM-105Z E CAPACITOR 1uF 50V M
C318 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C341 NDC31HJ-101X C CAPACITOR 100pF 50V J
C351 NDC31HJ-101X C CAPACITOR 100pF 50V J
C361 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C501 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C502 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C503 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C504 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C506 NDC31HJ-680X C CAPACITOR 68pF 50V J
C507 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C508 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C509 NCB31EK-563X C CAPACITOR 0.056uF 25V K
C510 NCB31EK-393X C CAPACITOR 0.039uF 25V K
C511 NCB31HK-272X C CAPACITOR 2700pF 50V K
C512 NCB31HK-272X C CAPACITOR 2700pF 50V K
C513 NDC31HJ-151X C CAPACITOR 150pF 50V J
C514 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C515 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C516 NDC31HJ-680X C CAPACITOR 68pF 50V J
C517 NCB31EK-823X C CAPACITOR 0.082uF 25V K
C518 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C520 NCB31HK-271X C CAPACITOR 270pF 50V K
C521 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C522 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C523 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C525 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C526 NDC31HJ-101X C CAPACITOR 100pF 50V J

Symbol No.
Part No. Part Name Description Local
