JVC KD-R691 Schematic Diagrams

(No.MA665<Rev.001>)21/33
4.3.4 CD Error Information Display Mode
Item Operation Display content Details
CD error
information
display mode
ACCENT
Transit to CD error information display mode.
CD Mecha error
log display
DISP
(Toggle)
Move
between
items with
/
Mecha error history 1,2,3 (latest)
#:History No. (1,2,3)
XX: kind of errors, "--" when there is none
00: No Error
04: TOC read Error
05: Unknown CD
06: Heat Error
0A: Update Error
0D: Hold Error
15: Unknown Disc
99: Mecha Error
CD Load error
information
display
Load error switch 1,2
#: Switch No. (1,2)
XX: numbers of errors, "--" when there is none
History No. 2 is un-used
CD Eject error
information
display
Eject error switch 1,2,3,4
#: History No. (1,2,3,4)
XX: numbers of errors, "--" when there is none
History No.3 is un-used
History No.1: Eject before SW1 is on.
History No.2: Eject until SW1 and SW2 is on.
History No.3: Eject between SW2 on and Eject end
CD time code
error count
information
display (count
skip)
CD time code error count information (count skip)
mode display
CD-DA error count numbers
XX: numbers of errors and "--" when there is none
CD-ROM (compressed file) error count numbers
XX: numbers of errors and “--” when there is none
CD time code
error count
information
display
(no count update)
CD time code error count information
(count not updated) mode display
CD-DA error count numbers
XX: numbers of errors and "--" when there is none
CD-ROM (compressed file) error count numbers
XX: numbers of errors and "--" when there is none
CD error
information clear
ACCENT
Clear CD error information by pressing for 2 seconds
when it is displayed.
Mode release
ACCENT
CD error information display mode release, All Lights
On
EMCHAE # X:XR
OLAD E# XX:R
JEECT E# XX:R
NCT OLSE
DCDA :XX
DCROM :XX
NCT TAYS
DCDA X:X
DCROM X:X
EMCHAE # X:XR
