ENGLISH
44
AUDIO AMPLIFIER SECTION
Maximum Power Output: Front/Rear: 50 W per channel
Continuous Power Output
(RMS):
Front/Rear: 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no
more than 0.8% total harmonic distortion.
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range: Low: ±12 dB (50 Hz, 100 Hz, 200 Hz)
Q0.7, Q1.0, Q1.4, Q2.0
Mid: ±12 dB (0.5 kHz, 1.0 kHz, 2.0 kHz)
Q0.7, Q1.0, Q1.4, Q2.0
High: ±12 dB (5.0 kHz, 10.0 kHz, 15.0 kHz)
Q0.7, Q1.0, Q1.4, Q2.0
Frequency Response: 40 Hz to 20 000 Hz
Signal-to-Noise Ratio: 70 dB
Line-Out Level/Impedance: 5.0 V/20 kΩ load (full scale)
Subwoofer-Out Level/Impedance: 5.0 V/20 kΩ load (full scale)
Output Impedance: 1 kΩ
Other Terminal: USB input terminal, USB cable, AUX (auxiliary) input
jack, CD changer jack
TUNER SECTION
Frequency Range: FM: 87.5 MHz to 108.0 MHz
AM: 531 kHz to 1 602 kHz
FM Tuner: Usable Sensitivity: 9.3 dBf (0.8 μV/75 Ω)
50 dB Quieting Sensitivity: 16.3 dBf (1.8 μV/75 Ω)
Alternate Channel Selectivity (400 kHz): 65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 40 dB
AM Tuner: Sensitivity: 20 μV
Selectivity: 40 dB
Specifications
EN40-45_KD-R905_001A_2.indd 44EN40-45_KD-R905_001A_2.indd 44 1/22/09 3:04:37 PM1/22/09 3:04:37 PM
