KD-S595
3-5
Item
Parts number Parts name Area
A
Parts list (CD mechanism)
Q'ty
Description
Block No. MBMM
1 30320101T
FRAME
1
2 30320102T
TOP COVER
1
3 30320115T
DANPER F
2
4 30320116T
DANPER R
1
11 303205505T
CHASSIS RIVET
1
12 303205503T
CHANGE P. RVT A
1
13 303205301T
CLAMPER ASS'Y
1
14 303205302T
SPINDLE MOTOR A
1
MDN-3BL3LSBS
15 30320502T
CLAMPER ARM
1
16 30320503T
CHANGE GEAR SPG
1
17 30320505T
CHANGE GEAR 2
1
18 30320506T
FEED GEAR
1
19 30320507T
FEED RACK
1
20 30320509T
CHANGE LOCK RAR
1
21 30320510T
FEED SW HOLDER
1
22 30320511T
PU SHAFT HOLDER
1
23 30320513T
CLAMPER SUB SPG
1
24 30320514T
FD SUB HOLDER
1
25 30320518T
TOP PLATE
1
26 30320519T
SELECT LOCK ARM
1
27 30320520T
TRIGGER ARM
1
28 30320521T
SLIDE HOOK
1
29 30320522T
PU SHAFT
1
30 30320525T
CLAMPER ARM SPG
1
31 30320526T
SELECT L ARM SP
1
32 30320538T
SUSPENSION SP R
1
33 30320529T
SELECT ARM R
1
34 30320530T
LINK PLATE
1
35 30320531T
LINK PLATE SPG
1
36 30320523T
CUSHION F
1
37 30320524T
CUSHION R
2
38 30320539T
SUSPENSION SP L
2
61 69011614T
PICKUP OPT-725
1
62 64180406T
DET SW ESE22
1
ESE22MH56
71 303210301T
CONN PWB ASS'Y
1
72 30321002T
MODE SW
1
MMS000690ZMB0
73 30321003T
LOAD MOTOR WIRE
1
74 30321005T
MODE SW WIRE
1
75 30321009T
SL WIRE
1
76 30321011T
WIRE HOLDER
1
77 19501403T
WIRE CLAMPER
1
81 303211301T
ROLLER SHAFT AS
1
82 303211501T
L GEAR PLATE RV
1
83 303211302T
LOADING PLATE A
1
84 303211502T
LOCK ARM RV ASS
1
85 303211303T
L/F MOTOR ASS'Y
1
FF030PK-10180
86 30321101T
LOADING GEAR 1
1
87 30321102T
LOADING GEAR 2
1
