JVC KD-S595 User Manual

KD-S595
3-6
Item
Parts number Parts name Area
A
Parts list (CD mechanism)
Q'ty
Description
Block No. MBMM
88 30321103T
LOADING GEAR 3
1
89 30321104T
LOADING GEAR 4
1
90 30321105T
LOADING GEAR 5
1
91 30321106T
LOADING GEAR 6
1
92 30321107T
LOADING GEAR 7
1
93 30321111T
ROLLER GUIDE
2
94 30321114T
ROLLER GUIDE SP
2
95 30321116T
DISC STOPPER AR
1
96 30321117T
DISC ST ARM SPG
1
97 30321118T
LD GEAR BRACKET
1
98 30321125T
L SIDE PLATE
1
99 30321131T
LOAD PLATE SPG
1
100 30321133T
LDG ROLLER
2
101 18211223T
COLLAR SCREW
1
111 9P0420031T
SCREW M2X3
6
TAP 2X3
112 9P0420041T
SCREW(M2 X 4)
2
TAP 2X4
113 9B0320041T
SCREW(M2 X 4)
1
BIND 2X4
114 9C0117183T
SCREW
2
SCR M1.7X1.8
115 9C0120203T
SCREW
1
SCR M2X2
116 9C0317503T
SCREW
1
T SCR M1.7X5
121 9W0130170T
PW 3.5X8X0.3
1
122 9W0513060T
HL WASHER
1
HLW1.85X5X0.13
123 9W0710070T
L WASHER
1
LW3.1X6X0.1
124 9E0100152T
E RING
1
S 1.5
125 9W0113020T
PW 2.1X4X0.13
1
