Audio Settings
Crossover settings
Below are the available setting items for 2-way crossover and 3-way
crossover.
CAUTION
Select a crossover type according to how the speakers are connected.
(Page 35, 36)
If you select a wrong type:
• The speakers may be damaged.
• The output sound level may be extremely high or low.
SPEAKER SIZE
Selects according to the connected speaker size for optimum performance.
• The frequency and slope settings are automatically set for the crossover of
the selected speaker.
• If
[NONE] is selected for the following speaker in [SPEAKER SIZE] , the [X ‘ OVER]
setting of the selected speaker is not available.
– 2-way crossover:
[TWEETER] of [FRONT] / [REAR] / [SUBWOOFER]
– 3-way crossover: [WOOFER]
X ‘ OVER (crossover)
•
[FRQ] / [F-HPFFRQ] / [R-HPFFRQ] / [SWLPF FRQ] / [HPFFRQ] / [LPFFRQ] : Adjusts the
crossover frequency for the selected speakers (high pass filter or low pass
filter).
If
[THROUGH] is selected, all signals are sent to the selected speakers.
•
[SLOPE] / [F-HPFSLOPE] / [R-HPFSLOPE] / [SWLPF SLOPE] / [HPFSLOPE] / [LPFSLOPE] :
Adjusts the crossover slope.
Selectable only if a setting other than
[THROUGH] is selected for the
crossover frequency.
•
[SW LPF PHASE] / [PHASE] : Selects the phase of the speaker output to be in line
with the other speaker output.
•
[GAINLEFT] / [GAINRIGHT] / [F-HPFGAIN] / [R-HPFGAIN] / [SWLPF GAIN] / [GAIN] : Adjusts
the output volume of the selected speaker.
2-way crossover setting items
[SPEAKER SIZE]
[FRONT] [SIZE]
[8CM]/[10CM]/[12CM]/[13CM]/[16CM]/
[17CM]/[18CM]/[4×6]/[5×7]/[6×8]/[6×9]/
[7×10]
[TWEETER]
[SMALL]/[MIDDLE]/[LARGE]/[NONE] (not
connected)
[REAR]*1
[8CM]/[10CM]/[12CM]/[13CM]/[16CM]/[17CM]/[18CM]/[4×6]/
[5×7]/[6×8]/[6×9]/[7×10]/[NONE] (not connected)
[SUBWOOFER]*2*3
[16CM]/[20CM]/[25CM]/[30CM]/[38CM OVER]/[NONE] (not
connected)
[X ' OVER]
[TWEETER] [FRQ]
[1KHZ]/[1.6KHZ]/[2.5KHZ]/[4KHZ]/[5KHZ]/
[6.3KHZ]/[8KHZ]/[10KHZ]/[12.5KHZ]
[GAIN LEFT]
[–08DB] to [00DB]
[GAIN RIGHT]
[–08DB] to [00DB]
[FRONT HPF] [F-HPF FRQ]
[30HZ]/[40HZ]/[50HZ]/[60HZ]/[70HZ]/[80HZ]/
[90HZ]/[100HZ]/[120HZ]/[150HZ]/[180HZ]/
[220HZ]/[250HZ]/[THROUGH]
[F-HPF SLOPE]
[–06DB]/[–12DB]/[–18DB]/[–24DB]
[F-HPF GAIN]
[–08DB] to [00DB]
[REAR HPF]*1 [R-HPF FRQ]
[30HZ]/[40HZ]/[50HZ]/[60HZ]/[70HZ]/[80HZ]/
[90HZ]/[100HZ]/[120HZ]/[150HZ]/[180HZ]/
[220HZ]/[250HZ]/[THROUGH]
[R-HPF SLOPE]
[–06DB]/[–12DB]/[–18DB]/[–24DB]
[R-HPF GAIN]
[–08DB] to [00DB]
