3-3
General Assembly
Block No. [M][1][M][M]
Symbol No. Part No. Part Name Description Local
1 LV22109-002A PWB BRACKET-L
2 LV44487-001A SPACER
3 LV44487-002A SPACER
4 LV40846-048A SPACER(F)
5 QYSDSG3006ZA TAP SCREW M3 x 6mm
6 QYSDSG3006ZA TAP SCREW M3 x 6mm
7 QYSDSG3008ZA TAP SCREW M3 x 8mm(x2)
8 QYSBST3006ZA TAP SCREW M3 x 6mm
9 QYSDSG3006ZA TAP SCREW M3 x 6mm(x2)
10 QYSDSG3008ZA TAP SCREW M3 x 8mm(x2)
11 LV36141-004A LED PWB BRACKET
12 LV36141-005A LED PWB BRACKET
13 LV22108-002A FRONT PANEL 2
14 QYSDSG3008MA TAP SCREW M3 x 8mm(x2)
15 QYSDSG3008MA TAP SCREW M3 x 8mm(x2)
16 QYSPSF2008MA TAP SCREW M2 x 8mm(x4)
17 QYSDSG3008MA TAP SCREW M3 x 8mm
18 QYSDSG3008MA TAP SCREW M3 x 8mm
19 LV11140-002A MAIN COVER
20 LV40847-031A SPACER(H) (x2)
21 LV36173-002A LED LENS
22 QYSDSG3008ZA TAP SCREW M3 x 8mm
23 LV36143-002A WINDOW FRAME
24 LV36241-002A WINDOW SHEET
25 LV36142-002A MESH WINDOW
26 QYSDSG3006MA TAP SCREW M3 x 6mm(x2)
27 LV22102-002A TOP COVER
28 LV40846-050A SPACER(F) (x2)
29 LV44496-001A SPACER
30 QYSDSG3010MA TAP SCREW M3 x 10mm(x3)
31 LV22118-001A TOP LED LENS
32 LV44458-003A SCREW (x5)
33 QYSDSG3010ZA TAP SCREW M3 x 10mm(x2)
34 LV22112-002A BOTTOM PLATE
35 QYSDSG3010MA TAP SCREW M3 x 10mm(x4)
36 QYSDSG3010MA TAP SCREW M3 x 10mm(x2)
37 LV22113-001A COVER-L
38 LV22114-001A COVER-R
39 QYYYSP4008RA BOLT M4 x 8mm(x6)
40 LV44484-001A SPACER
41 LV36746-001A NAME PLATE J
41 LV36725-001A NAME PLATE E,U
42 QMFZ047-400-T FUSE 40A(x2)
43 LV36139-003A SUB HEAT SINK-L
44 LV36140-003A SUB HEAT SINK-R
45 LV36138-003A SUB HEAT SINK-1 (x3)
46 LV44458-003A SCREW (x14)
47 QYSDSG3008ZA TAP SCREW M3 x 8mm(x10)
48 LV44458-002A ASSY T.SCREW (x8)
49 LV44458-001A ASSY T.SCREW (x2)
50 LV44388-002A SUB HS SHEET 1 (x3)
51 LV44389-002A SUB HS SHEET 1 (x2)
52 LV44385-001A RECYCLE LABEL E
