3-4
Electrical parts list
Main board
Block No. [0][1]

Symbol No.
Part No. Part Name Description Local
IC1 UPC494GS-X IC
IC501 NJM4580V-X IC
IC502 NJM4580V-X IC
IC521 NJM4580V-X IC
Q1 2SC5734K/QR/-X TRANSISTOR
Q2 2SA2054K/Q/-X TRANSISTOR
Q3 2SA2054K/Q/-X TRANSISTOR
Q4 2SC5734K/QR/-X TRANSISTOR
Q5 FKV550N POWER MOSFET
Q6 FKV550N POWER MOSFET
Q7 FKV550N POWER MOSFET
Q8 FKV550N POWER MOSFET
Q9 2SC5171 POW TRANSISTOR
Q10 2SA1930 POW TRANSISTOR
Q15 FKV550N POWER MOSFET
Q16 FKV550N POWER MOSFET
Q17 FKV550N POWER MOSFET
Q18 FKV550N POWER MOSFET
Q19 2SC3928A/R/-X TRANSISTOR
Q20 2SC3928A/R/-X TRANSISTOR
Q21 2SB1197K/QR/-X TRANSISTOR
Q22 2SC3928A/R/-X TRANSISTOR
Q23 2SC3928A/R/-X TRANSISTOR
Q25 2SA1530A/R/-X TRANSISTOR
Q26 2SC3928A/R/-X TRANSISTOR
Q27 2SC3928A/R/-X TRANSISTOR
Q28 2SA2054K/Q/-X TRANSISTOR
Q30 2SK368/Y/-X CHIP JFET.C.M
Q31 2SK368/Y/-X CHIP JFET.C.M
Q32 2SC3928A/R/-X TRANSISTOR
Q33 2SA1530A/R/-X TRANSISTOR
Q34 2SC3928A/R/-X TRANSISTOR
Q101 2SK198/R/-X CHIP JFET.C.M
Q102 2SC5734K/QR/-X TRANSISTOR
Q103 2SC5734K/QR/-X TRANSISTOR
Q104 2SA2054K/Q/-X TRANSISTOR
Q105 2SA2054K/Q/-X TRANSISTOR
Q106 2SA1930 POW TRANSISTOR
Q107 2SC5171 POW TRANSISTOR
Q108 2SC1815/GL/-T TRANSISTOR
Q109 2SC5171 POW TRANSISTOR
Q110 2SA1930 POW TRANSISTOR
Q111 MLE20 POWER MOSFET
Q112 MJD20 POWER MOSFET
Q113 MLE20 POWER MOSFET
Q114 MJD20 POWER MOSFET
Q115 MLE20 POWER MOSFET
Q116 MJD20 POWER MOSFET
Q119 2SC3138/Y/-X TRANSISTOR
Q120 2SA1255/Y/-X TRANSISTOR
Q130 2SC3928A/R/-X TRANSISTOR
Q131 2SA1530A/R/-X TRANSISTOR
Q132 2SC3138/Y/-X TRANSISTOR
Q133 2SA1255/Y/-X TRANSISTOR
Q134 2SK368/Y/-X CHIP JFET.C.M
Q135 2SC5734K/QR/-X TRANSISTOR
Q136 2SA2054K/Q/-X TRANSISTOR
Q137 2SA2054K/Q/-X TRANSISTOR
Q138 2SC5734K/QR/-X TRANSISTOR
Q201 2SK198/R/-X CHIP JFET.C.M
Q202 2SC5734K/QR/-X TRANSISTOR
Q203 2SC5734K/QR/-X TRANSISTOR
Q204 2SA2054K/Q/-X TRANSISTOR
Q205 2SA2054K/Q/-X TRANSISTOR
Q206 2SA1930 POW TRANSISTOR
Q207 2SC5171 POW TRANSISTOR
Q208 2SC1815/GL/-T TRANSISTOR
Q209 2SC5171 POW TRANSISTOR
Q210 2SA1930 POW TRANSISTOR
Q211 MLE20 POWER MOSFET
Q212 MJD20 POWER MOSFET
Q213 MLE20 POWER MOSFET
Q214 MJD20 POWER MOSFET
Q215 MLE20 POWER MOSFET
Q216 MJD20 POWER MOSFET
Q219 2SC3138/Y/-X TRANSISTOR
Q220 2SA1255/Y/-X TRANSISTOR
D1 FMG-22R SI DIODE
D3 1SS355-X SI DIODE E,U
D4 1SS355-X SI DIODE E,U
D5 FMG-32S SI DIODE
D6 FMG-32R SI DIODE
D7 UDZS15B-X Z DIODE
D8 UDZS15B-X Z DIODE
D11 1SR156-400-X DIODE C.M
D16 UDZS7.5B-X Z DIODE
D17 UDZS15B-X Z DIODE
D18 1SS355-X SI DIODE
D19 1SR156-400-X DIODE C.M
D22 1SS355-X SI DIODE
D23 1SS355-X SI DIODE
D27 1SS355-X SI DIODE
D30 1SR156-400-X DIODE C.M
D31 1SR156-400-X DIODE C.M
D37 1SS355-X SI DIODE
D101 1SS355-X SI DIODE
D102 1SS355-X SI DIODE
D103 1SR156-400-X DIODE C.M
D104 1SR156-400-X DIODE C.M
D105 1SS355-X SI DIODE
D106 1SS376-X SI DIODE
D110 1SS376-X SI DIODE
D111 1SS376-X SI DIODE
D112 1SS355-X SI DIODE
D113 1SS355-X SI DIODE
D201 1SS355-X SI DIODE
D202 1SS355-X SI DIODE
D203 1SR156-400-X DIODE C.M
D204 1SR156-400-X DIODE C.M
D205 1SS355-X SI DIODE
D206 1SS376-X SI DIODE
D210 1SS376-X SI DIODE
D211 1SS376-X SI DIODE
D212 1SS355-X SI DIODE
D213 1SS355-X SI DIODE
D503 MC2838-X DIODE
D504 MC2836-X DIODE
D507 MC2836-X DIODE
D509 MC2838-X DIODE
D591 SPR-39MVWF LED RED-GREEN
D603 MC2838-X DIODE
D604 MC2836-X DIODE
D607 MC2836-X DIODE
D609 MC2838-X DIODE
C3 QTMM1EM-338 E CAPACITOR 3300uF 25V M
C4 QTMM1EM-338 E CAPACITOR 3300uF 25V M
C6 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C8 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C9 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C10 QEZ0751-568 E CAPACITOR 5600uF
C11 QEZ0751-568 E CAPACITOR 5600uF
C12 NCZ1061-104X C CAPACITOR 0.1uF
C13 NCZ1061-104X C CAPACITOR 0.1uF
C14 QEKJ1HM-106Z E CAPACITOR 10uF 50V M
C15 QEKJ1HM-106Z E CAPACITOR 10uF 50V M
C16 QEKJ1HM-106Z E CAPACITOR 10uF 50V M
C17 QEKJ1HM-106Z E CAPACITOR 10uF 50V M
C18 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C19 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C20 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C22 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C23 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C24 QEZ0751-568 E CAPACITOR 5600uF
C25 QEZ0751-568 E CAPACITOR 5600uF
C27 QFV72AJ-104Z MF CAPACITOR 0.1uF 100V J E,U

