JVC KS-AX6700 User Manual

6
5
4
3
2
1
BCDEFGH I JA
7
KS-AX6700
2-4
Caution
If electricity is connected during disassembly, it must be a no load current. If it is load
current, be sure to attach a heat sink to the power-amp IC. This will be damaged if the
above precautions are not followed, as it does not have a sub heat sink attached to it.
Printed circuit boards
Main board
Surface side view

JVC KS-AX6700 Specifications

General

Brand	JVC
Model	KS-AX6700
Category	Amplifier
Language	English
