KS-AX6700
3-4
Item
Parts number Parts name Area
Remarks
C 101 ELE4.7/50VSMS CAPACITOR ELECTROLYTIC SM
C 102 ELE4.7/50VSMS CAPACITOR ELECTROLYTIC SM
C 104 CER22PF50VNPO CAPACITOR CERAMIC DISK 50
C 105 CER100PF50VNPO CAPACITOR CERAMIC DISK 50
C 106 CER22PF50VNPO CAPACITOR CERAMIC DISK 50
C 119 ELE4.7/50VSMS CAPACITOR ELECTROLYTIC SM
C 120 CER100PF50VNPO CAPACITOR CERAMIC DISK 50
C 121 CER104PF50V CAPACITOR CERAMIC DISK 50
C 122 CER104PF50V CAPACITOR CERAMIC DISK 50
C 123 CER104PF50V CAPACITOR CERAMIC DISK 50
C 124 CER104PF50V CAPACITOR CERAMIC DISK 50
C 142 CER104PF50V CAPACITOR CERAMIC DISK 50
C 143 MAL224J63VTL CAPACITOR MYLAR 5% 63V T
C 144 CER104PF50V CAPACITOR CERAMIC DISK 50
C 145 ELE100/63VSMS CARBON RESISTOR ELECTROLYTIC S
C 146 CER100PF50VNPO CAPACITOR CERAMIC DISK 50
C 147 CER100PF50VNPO CAPACITOR CERAMIC DISK 50
C 148 CER5PF50VNPO CAPACITOR CERAMIC DISK 50
C 149 ELE100/16VSMS CAPACITOR ELECTROLYTIC SM
C 160 ELE4.7/50VSMS CAPACITOR ELECTROLYTIC SM
C 161 ELE4.7/50VSMS CAPACITOR ELECTROLYTIC SM
C 162 CER102PF50VCH CAPACITOR AXIAL CERAMIC 5
C 163 CER102PF50VCH CAPACITOR AXIAL CERAMIC 5
C 171 ELE100/50VSMS CARBON RESISTOR ELECTROLYTIC S
C 172 CER102PF50V CAPACITOR CERAMIC DISK 50
C 173 ELE100/16VSMS CAPACITOR ELECTROLYTIC SM
C 190 ELE330/16VSMS CAPACITOR ELECTROLYTIC S
C 191 MAL104J63VTL CAPACITOR MYLAR 5% 63V T
C 201 ELE4.7/50VSMS CAPACITOR ELECTROLYTIC SM
C 202 ELE4.7/50VSMS CAPACITOR ELECTROLYTIC SM
C 204 CER22PF50VNPO CAPACITOR CERAMIC DISK 50
C 205 CER100PF50VNPO CAPACITOR CERAMIC DISK 50
C 206 CER22PF50VNPO CAPACITOR CERAMIC DISK 50
C 219 ELE4.7/50VSMS CAPACITOR ELECTROLYTIC SM
C 220 CER100PF50VNPO CAPACITOR CERAMIC DISK 50
C 242 CER104PF50V CAPACITOR CERAMIC DISK 50
C 243 MAL224J63VTL CAPACITOR MYLAR 5% 63V T
C 244 CER104PF50V CAPACITOR CERAMIC DISK 50
C 245 ELE100/63VSMS CARBON RESISTOR ELECTROLYTIC S
C 246 CER100PF50VNPO CAPACITOR CERAMIC DISK 50
C 247 CER100PF50VNPO CAPACITOR CERAMIC DISK 50
C 248 CER5PF50VNPO CAPACITOR CERAMIC DISK 50
C 249 ELE100/16VSMS CAPACITOR ELECTROLYTIC SM
C 260 ELE4.7/50VSMS CAPACITOR ELECTROLYTIC SM
C 261 ELE4.7/50VSMS CAPACITOR ELECTROLYTIC SM
C 262 CER102PF50VCH CAPACITOR AXIAL CERAMIC 5
C 263 CER102PF50VCH CAPACITOR AXIAL CERAMIC 5
C 291 MAL104J63VTL CAPACITOR MYLAR 5% 63V T
C 345 ELE470/16VSMS CAPACITOR ELECTROLYTIC S
C 701 ELE10/25VSMS CAPACITOR ELECTROLYTIC SM
C 705 ELE47/25VSMS CAPACITOR ELECTROLYTIC SM
C 706 CER104PF50V CAPACITOR CERAMIC DISK 50
C 715 CER104PF50V CAPACITOR CERAMIC DISK 50
C 716 MAL334J63VTL CAPACITOR MYLAR 5% 63V T
C 717 ELE47/16VSMS CAPACITOR ELECTROLYTIC SM
C 718 ELE220/16VSMS CAPACITOR ELECTROLYTIC S
C 720 CER104PF50V CAPACITOR CERAMIC DISK 50
C 721 ELE10/25VSMS CAPACITOR ELECTROLYTIC SM
C 722 ELE47/25VSMS CAPACITOR ELECTROLYTIC SM
C 724 CER104PF50V CAPACITOR CERAMIC DISK 50
C 725 ELE10/100VSMS CAPACITOR ELECTROLYTIC SM
C 726 CER104PF50V CAPACITOR CERAMIC DISK 50
C 727 ELE10/100VSMS CAPACITOR ELECTROLYTIC SM
C 728 ELE10/100VSMS CAPACITOR ELECTROLYTIC SM
C 731 ELE100/16VSMS CAPACITOR ELECTROLYTIC SM
C 740 MAL102J CAPACITOR STICON
C 741 ELE47/25VSMS CAPACITOR ELECTROLYTIC SM
C 750 ELE2200/25VRX CAPACITOR ELECTROLYTIC R
C 751 ELE2200/25VRX CAPACITOR ELECTROLYTIC R
C 752 CER104PF50V CAPACITOR CERAMIC DISK 50
C 753 ELE1000/35VRX CAPACITOR ELECTROLYTIC R
C 760 MAL222J63VTL CAPACITOR MYLAR 5% 63V T
C 761 ELE2.2/50VSMS CAPACITOR ELECTROLYTIC SM
C 762 ELE4.7/50VSMS CAPACITOR ELECTROLYTIC SM
C 763 ELE47/25VSMS CAPACITOR ELECTROLYTIC SM
C 765 CER104PF50V CAPACITOR CERAMIC DISK 50
C 766 CER104PF50V CAPACITOR CERAMIC DISK 50
C 767 ELE1000/50VSD CAPACITOR ELECTROLYTIC S
C 768 ELE1000/50VSD CAPACITOR ELECTROLYTIC S
C 769 ELE2200/50VSHL CAPACITOR ELECTROLYTIC S
C 770 ELE2200/50VSHL CAPACITOR ELECTROLYTIC S
C 771 ELE2200/50VSHL CAPACITOR ELECTROLYTIC S
C 772 ELE2200/50VSHL CAPACITOR ELECTROLYTIC S
C 773 MAL105J63VTL CAPACITOR MYLAR 5% 63V T
C 774 MAL105J63VTL CAPACITOR MYLAR 5% 63V T
C 780 CER22PF50VNPO CAPACITOR CERAMIC DISK 50
C 781 ELE10/50VMS CAPACITOR ELECTROLYTIC SM
C 785 ELE100/35VSMS CAPACITOR ELECTROLYTIC SM
C 786 ELE100/35VSMS CAPACITOR ELECTROLYTIC SM
C 787 CER104PF50V CAPACITOR CERAMIC DISK 50
C 788 CER104PF50V CAPACITOR CERAMIC DISK 50
C 790 CER473PF50V CAPACITOR CERAMIC DISK 50
C 791 MAL105J63VTL CAPACITOR MYLAR 5% 63V T
C 792 CER473PF50V CAPACITOR CERAMIC DISK 50
C 850 ELE10/25VSMS CAPACITOR ELECTROLYTIC SM
C 861 CER223PF50V CAPACITOR CERAMIC DISK 50
C 862 CER104PF50V CAPACITOR CERAMIC DISK 50
C 863 MAL103J63VTL CAPACITOR MYLAR 5% 63V T
C 864 MAL103J63VTL CAPACITOR MYLAR 5% 63V T
C 867 CER104PF50V CAPACITOR CERAMIC DISK 50
CON01 LWL0640-2P WAFER
D 142 1N4148 GE DIODE SWITCHING SIGNA
D 143 1N4148 GE DIODE SWITCHING SIGNA
D 151 1N5235 DIODE ZENER 6.8V
D 170 1N4148 GE DIODE SWITCHING SIGNA
D 242 1N4148 GE DIODE SWITCHING SIGNA
D 243 1N4148 GE DIODE SWITCHING SIGNA
D 251 1N5235 DIODE ZENER 6.8V
D 701 1N5404 CARBON RESISTOR RECTIFIER
D 702 1N4004 DIODE RECTIFIER
D 704 1N4148 GE DIODE SWITCHING SIGNA
D 710 1N4148 GE DIODE SWITCHING SIGNA
D 711 1N4148 GE DIODE SWITCHING SIGNA
D 722 PR1504 DIODE FAST RECOVERY
D 723 PR1504 DIODE FAST RECOVERY
D 731 PR1504 DIODE FAST RECOVERY
D 732 PR1504 DIODE FAST RECOVERY
D 734 PR1504 DIODE FAST RECOVERY
D 735 PR1504 DIODE FAST RECOVERY
D 751 ESC25M02-D DIODE FAST RECOVERY
D 752 ESC25M02-D DIODE FAST RECOVERY
D 770 1N4148 GE DIODE SWITCHING SIGNA
D 771 1N4148 GE DIODE SWITCHING SIGNA
D 850 1N4148 GE DIODE SWITCHING SIGNA
F 1 FUSE25A/32V FUSE
A
TEFLON TUBE
F 2 FUSE25A/32V FUSE
A
TEFLON TUBE
Electrical parts list ( MAIN PCB )
Block No. 01
A
Item
Parts number Parts name Area
Remarks
A
Eiectrical parts list
