KS-AX6700
1-4
CCFL P.C. board
Wire assemb'y
(from Main)
Main P.C. board
GND wire
Heat sink
(Bottom view)
Sub1 P.C. board
Main P.C. board
Sub2 P.C. board
2pin connector
(to CCFL P.C. board)
