6
Screen (touch panel) Monitor panel
1 Loading slot
2 0 (Eject) button
Ejects the disc.
3 HOME/DISP OFF button
• Displays the <HOME> screen. (Press)
(☞ page 12)
• Turns off/on the screen. (Hold) (☞ page 9)
4 SRC /
button
• Turns off the power. (Hold) (☞ page 9)
• Turns on the power. (Press) (☞ page 9)
• Selects the AV source. (Press) (☞ page 12)
Caution on the volume setting:
Digital devices produce very little noise compared
with other sources. Lower the volume before
playing these digital sources to avoid damaging
the speakers by sudden increase of the output
level.
Component names and functions
5 VOLUME/ATT knob. (☞ page 9)
• Attenuates the sound. (Press)
• Adjusts the audio volume. (Turn)
6 Remote sensor
7 Reset button
Resets the unit. (☞ page 3)
8 AUX input jack
9
(Detach) button
Detaches the monitor panel. (☞ page 5)
You can change the color of the buttons on the
monitor panel. (☞ page 38)
