15
English |
Installation
Ñ Connecting an iPhone/Android
ANT
CAM IN VIDEO OUT VIDEO IN
AV IN
L
R
FRONT OUTREAR OUT
M4x6
2 4 6 8
1 3 5 7
2 4 6 8
1 3 5 7
P.CONT
ANT.CONT
Accessory 6
Accessory 5
Blue
(Power control/ Antenna control wire)
Connect either to the power control
terminal when using the optional power
amplier, or to the power terminal for
the booster amplier of the lm-type or
short pole type antenna.
(Max. 150mA, 12V)
White/Black
Gray/Black
Green/Black
Purple/Black
Speaker impedance: 4-8 Ω
Purple
Green
Gray
White
To front left speaker
To front right
speaker
To rear left speaker
To rear right
speaker
Cap
Red (Ignition wire)
Black (Ground wire) ¤
(To car chassis)
Yellow (Battery wire)
Ignition key switch
Car fuse box
ACC
Battery
[1]
USB maximum power supply current :
DC 5 V = 1.5 A
[2]
Sold separately
ANT
CAM IN VIDEO OUT VIDEO IN
AV IN
L
R
FRONT OUTREAR OUT
M4x6
5V
=
1.5A
USB cable
[2]
Android smartphone
[2]
Cap
USB terminal
[1]
(1.0 m)
Lightning-USB cable
[2]
iPhone
[2]
