JVC KY-PZ100 User Manual

32
Multi-Camera Connection
Using SDI (2)
This is a simple setup to remotely control the PTZ cameras.
SDI output with no video drift between cameras is recommended in this multi-
camera setup.
Thesetupcanbesimpli󰼎edbyselectingaswitcherwithbuilt-inaudiomixer.
For system in which PC is not used, control the camera with the remote
camera controller (RM-LP100).
Lag may occur depending on the network environment.
Model No. Description Quantity
KY-PZ100 HD PTZ Remote Camera 3
RM-LP100 Remote Camera Controller 1
DT-V24G2 * Multi-Format LCD Monitor 2
SR-HD2700 Blu-Ray Disc & HDD Recorder 1
HUB(PoE+) 1
Blackmagic Design
ATEM Television Studio,
Blackmagic MultiView 4
/ datavideo SE-2200 /
For-A HVS-100 / Roland
V-1SDI, V-800HD
Switcher 1
Audio System 1
SDI Cable 5
LAN Cable (Category 5e) 4
Audio Cable (Stereo) 2
HDMI Cable 1
* Selectable
