Technical Information and Help
Product Fiche and Specifications
Brand JVC
Model LT-32C670(B) / LT-32C671(B)
Energy Efficiency Class A+
Screen Size (measured diagonally) 32" - 81cm
Power Consumption (In HOME mode) 31W
Average Annual Energy Consumption ** 45 kWh / annum
Standby Power Consumption 0.5W
Display Resolution 1366 pixels (horizontal) x 768 pixels (vertical)
Panel System 32 inch Direct lit LED Panel
Television System
PAL I / BG / DK
DVB-T2 (VIDEO: MPEG-4 MP@ML,
SOUND: AAC, MPEG-1 LAYER 1/2, MPEG-2 LAYER 2)
Brightness 250 cd/m
2
Contrast Ratio 4000 : 1
Power Source 220-240V ~50Hz
Operating Temperature 0°C – 40°C
Operating Humidity 80% (max)
Mercury Content (mg) X
Presence of Lead √*
Reference Period 2010/1062 - 2017
Speaker Power 2 x 6W
Dimension( W x H x D) with base 735(W) x 478(H) x 185(D)
Weight (Net) 5.4kg
Inputs / Output
SCART 1
HDMI 2 (HDMI 1 with ARC)
PC-RGB (VGA) 1
SIDE AV (L & R) 1
YPbPr via VGA 1
Common Interface 1
USB 1
ANT. (Aerial socket) 1
SPDIF (Optical) 1
Headphone 1
Ethernet (RJ-45) 1
Built in wireless network Yes
Features and specifications are subject to change without prior notice.
*This television contains lead in certain parts or components where no technology alternatives exist in accordance with existing
exemption clauses under the RoHS Directive.
**Energy consumption 45 kWh per year, based on the power consumption of the television operating 4 hours per day for 365
days. The actual energy consumption will depend on how the television is used.
Wireless LAN Transmitter
Frequency Ranges Max Output Power
2400 - 2483,5 MHz (CH1-CH13) < 100 mW
5150 - 5250 MHz (CH36 - CH48) < 200 mW
5250 - 5350 MHz (CH52 - CH64) < 200 mW
5470 - 5725 MHz (CH100 - CH140) < 200 mW
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 60 11/09/2018 10:19
