3-32(No.YA462)
DC-DC P.W. BOARD ASS'Y (SFL-9177A-BK)
DIGITAL P.W. BOARD ASS'Y (SFL0D361A-BK)
 T9502 QQS0347-002 SW TRANSF
 CP9201 QMFZ052-2R0-E FUSE 2A AC250V
 CP9501 QMFZ043-2R0Z-J1 FUSE 2A AC250V
 CP9551 QMFZ034-5R0Z-J1 FUSE 5A 125V
 CP9552 QMFZ034-5R0Z-J1 FUSE 5A 125V
 F9001 QMF5AD2-6R3-J1 FUSE 6.3A AC250V
K9502 QQR0621-002Z FERRITE BEADS
K9503 QQR0621-002Z FERRITE BEADS
K9551 NQR0499-001X FERRITE BEADS
K9552 NQR0499-002X FERRITE BEADS
K9553 NQR0499-002X FERRITE BEADS
K9554 NQR0499-002X FERRITE BEADS
K9555 NQR0499-002X FERRITE BEADS
K9556 NQR0499-002X FERRITE BEADS
K9557 NQR0499-002X FERRITE BEADS
 LF9001 QQR1376-002 LINE FILTER
 LF9002 QQR1281-005 LINE FILTER
 LF9003 QQR1514-001 LINE FILTER
 PC9202 PS2581AL2/QW/-W PHOTO COUPLER
 PC9501 PS2581AL2/QW/-W PHOTO COUPLER
 PC9502 PS2581AL2/QW/-W PHOTO COUPLER
 PC9503 PS2581AL2/QW/-W PHOTO COUPLER
 RY9001 QSK0162-001 RELAY
 RY9002 QSK0162-001 RELAY
 VA9001 QAF0028-621 VARISTOR 620V
 Ref No. Part No. Part Name Description Local
IC9601 MP2363DN-X IC
IC9602 MP2363DN-X IC
IC9603 LM393DR-X IC
IC9801 MP2363DN-X IC
IC9851 BA09FP-X IC
Q9601 2SC3928A/QR/-X TRANSISTOR
Q9651 2SC3928A/QR/-X TRANSISTOR
Q9801 2SC3928A/QR/-X TRANSISTOR
D9601 EC30HA04-X SB DIODE
D9602 1SS355W-X DIODE
D9602 MA111-X SI DIODE
D9603 UDZW3.0B-X Z DIODE
D9603 MA8030/H/-X Z DIODE
D9604 PTZ6.8B-X Z DIODE
D9605 EC30HA04-X SB DIODE
D9606 EC30HA04-X SB DIODE
D9652 EC30HA04-X SB DIODE
D9653 EC30HA04-X SB DIODE
D9654 PTZ16B-X Z DIODE
D9655 1SS355W-X DIODE
D9655 MA111-X SI DIODE
D9681 UDZS9.1B-X Z DIODE
D9682 1SS355W-X DIODE
D9682 MA111-X SI DIODE
D9801 EC30HA04-X SB DIODE
D9802 EC30HA04-X SB DIODE
D9803 1SS355W-X DIODE
D9803 MA111-X SI DIODE
C9601 NCJ41HK-335X-U C CAPACITOR 3.3uF 50V K
C9603 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9604 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9605 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9606 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C9606 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9607 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9608 NCB31HK-332X C CAPACITOR 3300pF 50V K
C9610 NEHM1HM-105X E CAPACITOR 1uF 50V M
C9651 NCJ41HK-335X-U C CAPACITOR 3.3uF 50V K
C9652 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9654 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9655 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9656 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C9656 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9657 NDC31HJ-101X C CAPACITOR 100pF 50V J
C9658 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9660 NBZ0010-396X SP E CAPACITOR 39uF 16V M
C9681 NEHM1HM-105X E CAPACITOR 1uF 50V M
C9682 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9683 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9684 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9801 NCJ41HK-335X-U C CAPACITOR 3.3uF 50V K
C9802 NCJ41HK-335X-U C CAPACITOR 3.3uF 50V K
C9803 NCB31HK-103X C CAPACITOR 0.01uF 50V K
 Ref No. Part No. Part Name Description Local
C9804 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9805 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9809 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C9851 NEHM1EM-336X E CAPACITOR 33uF 25V M
C9852 NEHM1EM-336X E CAPACITOR 33uF 25V M
R9601 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9602 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9603 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R9604 NRVA02D-473X CMF RESISTOR 47k
Ω 1/10W D
R9605 NRSA63J-225X MG RESISTOR 2.2M Ω 1/16W J
R9606 NRSA63D-103X MG RESISTOR 10k
Ω 1/16W D
R9607 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R9608 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R9609 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R9610 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R9651 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9652 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R9653 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R9654 NRSA63D-154X MG RESISTOR 150k Ω 1/16W D
R9655 NRSA63J-684X MG RESISTOR 680k Ω 1/16W J
R9656 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R9657 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R9658 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R9659 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R9660 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R9661 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R9668 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9681 NRS12BJ-332W MG RESISTOR 3.3k Ω 1/2W J
R9682 NRSA63D-472X MG RESISTOR 4.7k Ω 1/16W D
R9683 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R9684 NRSA63D-472X MG RESISTOR 4.7k
Ω 1/16W D
R9685 NRSA63D-273X MG RESISTOR 27k
Ω 1/16W D
R9686 NRSA63D-472X MG RESISTOR 4.7k Ω 1/16W D
R9801 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9802 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R9803 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9804 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R9805 NRSA63D-684X MG RESISTOR 680k Ω 1/16W D
R9806 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9807 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R9808 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R9809 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R9852 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9924 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R9928 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L9602 NQLC8CM-150X COIL 15uH M
L9652 NQLC8CM-150X COIL 15uH M
L9653 NQR0562-003X CHOKE COIL
L9802 NQLC8CM-150X COIL 15uH M
 Ref No. Part No. Part Name Description Local
IC6001 JCC5060 IC
IC6002 SN74LVC1G08V-X IC
IC6101 EDD1232AAFA-6B IC
IC6102 SC2595STRT-X IC
IC6250 UPC5702GS-027-X IC
IC6251 R1170H331B-X IC
IC6301 SN74AHCT1G08V-X IC
IC6302 SN74AHCT1G08V-X IC
IC6401 ISL98001CQZ-140 IC
IC6402 R1170H331B-X IC
IC6502 THC63LVDM83R-W IC
IC6724 S-80928CLNB-G-W IC
IC7033 CD74HC4094PW-X IC
IC7036 ADC081S021CIS-X IC
IC7038 SN74LVC2G17KE-X ZC
IC7201 39VF800A7IEKD16 IC(MICRO C ROM)
IC7203 M12L16161A-7TG IC
IC7204 S-80928CLNB-G-W IC
IC7205 SN74LV00APW-X IC
IC7301 SDA6000-B12 IC
IC7303 K4S641632K-UC75 IC
IC7304 CD74HC4053PW-X IC
IC7305 MM1689CH-X IC
IC7306 S-80928CLNB-G-W IC
IC7602 ATF32-Z37EX6 IC (SERVICE)
IC7606 MM1671XN-X IC
IC9001 MP2263DN-C053-X IC
IC9101 MM1662FT-X IC
IC9201 MP2263DN-C053-X IC
IC9301 MM1701CH-X IC
 Ref No. Part No. Part Name Description Local
