JVC MX-K30R User Manual

 Electrical parts list (K10/30/15 FRONT DISPLY UICOM SELECTION )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
1 O C701 NCB31EK-104X C CAPACITOR 0.1
2 O C702 QETM0JM-227 E CAPACITOR 220/6.3V
3 O C703 QETM0JM-227 E CAPACITOR 220/6.3V
4 O C704 QETM0JM-227 E CAPACITOR 220/6.3V
5 O C705 NCB31HK-102X C CAPACITOR 0.001
6 O C706 NCB31HK-102X C CAPACITOR 0.001
7 O C707 NDC31HJ-390X C CAPACITOR 39P
8 O C708 NDC31HJ-330X C CAPACITOR 33P
9 O C709 NDC31HJ-220X C CAPACITOR 22P
10 O C710 NDC31HJ-220X C CAPACITOR 22P
11 O C711 NDC31HJ-220X C CAPACITOR 22P
12 O C712 NDC31HJ-220X C CAPACITOR 22P
13 O C713 NCB31EK-104X C CAPACITOR 0.1
14 O C714 NCB31HK-103X C CAPACITOR 0.01
15 O C715 NCB31HK-102X C CAPACITOR 0.001
16 O C716 QETM1AM-476 E CAPACITOR 47/10V
17 O C717 NCB31EK-104X C CAPACITOR 0.1
18 O C718 QETM1HM-226 E CAPACITOR 22uF/50V
19 O C719 QETM1HM-226 E CAPACITOR 22uF/50V
20 O C720 NDC31HJ-151X C CAPACITOR 150P
21 O C721 NDC31HJ-151X C CAPACITOR 150P
22 O C723 QETM1HM-105 E CAPACITOR 1uF/50V
23 O C740 NDC31HJ-101X C CAPACITOR 100P
24 O C1001 NCB31HK-103X C CAPACITOR 0.01
25 O C1002 NCB31HK-103X C CAPACITOR 0.01
26 O CN701 12S120038 FFC CONNECTOR 12P H 1.25mm
27 O CN702 12S210005 FFC CONNECTOR 21P H 1.25mm
28 O CN703 12S220005 FFC CONNECTOR 22P H 1.25mm
29 O D701 11ES2-T4 SI DIODE 1SS133
30 O D702 11ES2-T4 SI DIODE 1SS133
31 O D703 11ES2-T4 SI DIODE 1SS133
32 O D705 11ES2-T4 SI DIODE 1SS133
33 O FL701 2701601 FL DISPLAY BJ828GNK
34 O FW701 1204091 CONN. WIRE 10PIN FLAT CABLE
35 O FW702 1203941 CONN. WIRE 3PIN FLAT CABLE
36 O FW703 1203931 CONN. WIRE 3PIN FLAT CABLE
37 O IC701 113171 IC MN101C35D
38 O IC702 RPM6938-SV4 IR.UNIT IC RPM6938-V4
39 O JK1 NIL MIC JACK NO MOUNT
40 O JR701 NRSA63J-0R0X MG RESISTOR NO MOUNT
41 O JR702 NRSA63J-0R0X MG RESISTOR 0
42 O JR749 NRSA63J-0R0X MG RESISTOR 0
43 O L701 26220000KN0024 FIXED INDUCTOR 22uH
44 O L702 26100000KM0024 FIXED INDUCTOR 10uH
45 O L703 18A843556N0002 F-BEAD F.B 843556
46 O L707 26100000KM0024 FIXED INDUCTOR 10uH
47 O ED100 28B4531EP0110 RED LED BL-B4531E
48 O Q701 2KTC3199GP0008 TRANSISTOR KTC3199GR
49 O Q702 2KTC3199GP0008 TRANSISTOR KTC3199GR
50 O Q703 2KTC3199GP0008 TRANSISTOR KTC3199GR
51 O Q704 2KTC3195YP0008 TRANSISTOR KTC3195Y
52 O Q705 2KTC3195YP0008 TRANSISTOR KTC3195Y
53 O Q707 DTC114YSA-T D.TRANSISTOR DTC114YS
54 O Q711 KRA102M-T D.TRANSISTOR KRA102M
55 O Q712 KRA102M-T D.TRANSISTOR KRA102M
3-11
