3-7
Amplifier board
Block No. [0][2]
R242 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R243 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R244 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R245 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R246 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R247 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R341 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R342 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R441 QRK126J-4R7X UNF C RESISTOR 4.7
Ω
1/2W J
R442 QRK126J-362X UNF C RESISTOR 3.6k
Ω
1/2W J
R443 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R444 QRJ146J-182X UNF C RESISTOR 1.8k
Ω
1/4W J
R895 QRJ146J-470X UNF C RESISTOR 47
Ω
1/4W J
R901 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R902 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R903 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R904 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R905 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R906 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R907 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R908 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R909 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R910 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R911 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R912 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R919 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R920 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R930 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R931 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R932 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R933 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R935 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R936 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R937 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R938 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R939 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R940 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R941 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R942 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R943 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R944 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R947 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R948 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R949 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R950 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R953 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R954 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R955 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R956 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1001 QRZ9037-335 COMP RESISTOR 3.3M
Ω
1/2W K
R1002 QRZ9037-335 COMP RESISTOR 3.3M
Ω
1/2W K
R1114 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R1151 NRSA63J-362X MG RESISTOR 3.6k
Ω
1/16W J
R1152 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R1153 NRSA63F-222X MG RESISTOR 2.2k
Ω
1/16W F
R1154 NRSA63F-332X MG RESISTOR 3.3k
Ω
1/16W F
R1155 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1156 NRSA63J-124X MG RESISTOR 120k
Ω
1/16W J
R1157 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1158 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R1159 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1160 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1161 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R1162 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1163 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R1164 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1165 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R1166 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R1169 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R1170 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1172 NRSA02J-332X MG RESISTOR 3.3k
Ω
1/10W J
R1173 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1174 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R1175 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R1176 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1178 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R1179 NRSA63F-332X MG RESISTOR 3.3k
Ω
1/16W F
R1180 NRSA63J-133X MG RESISTOR 13k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R1295 QRJ146J-470X UNF C RESISTOR 47
Ω
1/4W J
R1391 QRJ146J-470X UNF C RESISTOR 47
Ω
1/4W J
R1491 QRJ146J-470X UNF C RESISTOR 47
Ω
1/4W J
R1575 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R6595 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
T102 QQT0478-001 POWER TRANSF
BK901 LV34673-001A FL HOLDER(L)
BK902 LV34687-001A FL HOLDER(R)
CN120 QGA7901C1-02 CONNECTOR W-B (1-2)
CN151 QGB2510K1-12 CONNECTOR B-B (1-12)
CN202 QJK002-071802-E SIN CR C-B WIRE
CN206 WJK0208-002A-E E-SI C WIRE C-B
CN209 QGA2501C1-06 CONNECTOR W-B (1-6)
CN211 QJK012-034003-E SIN CR C-B WIRE
CN262 QGA3901C1-08 CONNECTOR W-B (1-8)
CN265 QGA3901C1-06 CONNECTOR W-B (1-6)
CN465 QGA2001C1-03 CONNECTOR W-B (1-3)
CN524 QGA2501C1-02 CONNECTOR W-B (1-2)
CN565 QGA2501C1-02 CONNECTOR W-B (1-2)
CN902 QGF1205F1-05 CONNECTOR FFC/FPC (1-5)
CN903 QJK021-070802-E SIN CR C-B
CN913 QGA2001F1-07 CONNECTOR W-B (1-7)
CN914 QGA2001F1-03 CONNECTOR W-B (1-3)
CN952 QJK021-124402-E SIN CR C-B WIRE
DI901 QLF0157-001 FL TUBE
EP151 QNZ0136-001Z EARTH PLATE
FC103 QNG0020-001Z FUSE CLIP
FC113 QNG0020-001Z FUSE CLIP
FS900 VYSH101-009 SPACER
FS901 VYSH101-009 SPACER
FW121 WJS0042-001A-E E-FL/RB WIRE
FW451 WJS0046-003A-E E-FL/RB WIRE
J504 QNN0480-001 PIN JACK
J505 QNS0089-001 3.5 JACK
JS901 QSW1129-001 ROTARY ENCODER
JS902 QSW1129-001 ROTARY ENCODER
RY101 QSK0128-001 RELAY
RY295 QSK0127-001 RELAY
RY391 QSK0127-001 RELAY
RY491 QSK0127-001 RELAY
RY895 QSK0127-001 RELAY
S901 QSW0683-001Z PUSH SW
S902 QSW0683-001Z PUSH SW
S903 QSW0683-001Z PUSH SW
S904 QSW0683-001Z PUSH SW
S905 QSW0683-001Z PUSH SW
S906 QSW0683-001Z PUSH SW
ST292 QNB0256-001 SPK TERMINAL
ST295 QNB0078-002 SPK TERMINAL
X241 QAX0734-001 C RESONATOR 400.00kHz
X242 QAX0735-001 C RESONATOR 420.00kHz
X901 QAX0246-001Z C RESONATOR 8.00MHz
Symbol No.
Part No. Part Name Description Local
IC101 IRS2011S-X IC
IC151 KIA7805API IC
IC152 KIA7809API IC
IC153 KIA7805API IC
IC201 JCV8015-X IC
IC202 SN74LVC3G04T-X IC
IC251 IRS20124S-X IC
IC261 IRS20124S-X IC
IC301 JCV8015-X IC
IC302 SN74LVC3G04T-X IC
IC351 IRS20124S-X IC
IC361 IRS20124S-X IC
IC401 JCV8015-X IC
IC451 IRS20124S-X IC
Symbol No.
Part No. Part Name Description Local
