JVC RX-D402B User Manual

3-20
DSP board
Block No. [0][5]
K3501 NQR0489-001X FERRITE BEADS
K3502 NQR0489-001X FERRITE BEADS
K3503 NQR0489-001X FERRITE BEADS
K3504 NQR0489-001X FERRITE BEADS
K3505 NQR0489-001X FERRITE BEADS
K3601 NQR0489-001X FERRITE BEADS
K3602 NQR0489-001X FERRITE BEADS
K3701 NQR0489-001X FERRITE BEADS
K3702 NQR0489-001X FERRITE BEADS
K3703 NQR0489-001X FERRITE BEADS
K3704 NQR0489-001X FERRITE BEADS
K3761 NQR0489-001X FERRITE BEADS
K3801 NQR0489-001X FERRITE BEADS
K3802 NQR0489-001X FERRITE BEADS
K3803 NQR0489-001X FERRITE BEADS
K3804 NQR0489-001X FERRITE BEADS
K3805 NQR0489-001X FERRITE BEADS
K3811 NQR0489-001X FERRITE BEADS
K3812 NQR0489-001X FERRITE BEADS
X731 NAX0805-001X CRYSTAL
X761 NAX0663-001X C RESONATOR
X771 NAX0633-001X CRISTAL
X781 NAX0394-001X CRISTAL
 Symbol No. Part No. Part Name Description Local
IC601 NJM4565M-WE IC
IC602 NJM4565M-WE IC
IC610 MN35505-X IC
IC611 NJM4565M-WE IC
IC612 NJM4565M-WE IC
IC613 NJM4565M-WE IC
IC614 NJM4565M-WE IC
IC620 MN35505-X IC
IC621 NJM4565M-WE IC
IC622 NJM4565M-WE IC
IC630 MN35505-X IC
IC631 NJM2120M-X IC
IC632 NJM4565M-WE IC
IC633 NJM4565M-WE IC
IC634 NJM4565M-WE IC
IC651 NJM4565M-WE IC
IC652 NJM4565M-WE IC
IC661 D601A002BPYP225 IC
IC662 SN74LVC1GU04K-X IC
IC663 ------------ IC
IC663 SA16M90TFIR12B IC(PROGRAMED)
IC664 K4S641632H-UC75 IC
IC671 UPD784215AGC291 IC
IC672 SN74AHCT1G32K-X IC
IC685 SN74LV157APW-X IC
IC686 SN74LV157APW-X IC
IC691 BA3259HFP-W IC
IC692 MM1563DF-X IC
IC697 CS42518-CQZ-D-W IC
Q2101 2SD2114K/VW/-X TRANSISTOR
Q2102 2SD2114K/VW/-X TRANSISTOR
Q2141 2SD601A/RS/-X TRANSISTOR
Q2142 2SD601A/RS/-X TRANSISTOR
Q2201 2SD2114K/VW/-X TRANSISTOR
Q2202 2SD2114K/VW/-X TRANSISTOR
Q2221 2SD2114K/VW/-X TRANSISTOR
Q2222 2SD2114K/VW/-X TRANSISTOR
Q2223 2SD2114K/VW/-X TRANSISTOR
Q2224 2SD2114K/VW/-X TRANSISTOR
Q2301 2SD2114K/VW/-X TRANSISTOR
Q2341 2SD601A/RS/-X TRANSISTOR
Q2401 2SD2114K/VW/-X TRANSISTOR
Q2421 2SD2114K/VW/-X TRANSISTOR
Q2422 2SD2114K/VW/-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q2501 2SD2114K/VW/-X TRANSISTOR
Q2502 2SD2114K/VW/-X TRANSISTOR
Q2701 UN2214-X TRANSISTOR
Q2702 UN2214-X TRANSISTOR
Q2704 UN2114-X TRANSISTOR
Q2705 UN2114-X TRANSISTOR
Q2706 UN2114-X TRANSISTOR
Q2708 UN2114-X TRANSISTOR
Q2709 UN2114-X TRANSISTOR
Q2710 UN2214-X TRANSISTOR
C2001 NEAF1EM-475X E CAPACITOR 4.7uF 25V M
C2002 NEAF1EM-475X E CAPACITOR 4.7uF 25V M
C2005 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2006 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2009 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2010 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2013 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2014 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2018 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C2019 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2020 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2101 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2102 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2109 NEAF1HM-475X E CAPACITOR 4.7uF 50V M
C2110 NEAF1HM-475X E CAPACITOR 4.7uF 50V M
C2111 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2112 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2113 NCB31HK-331X C CAPACITOR 330pF 50V K
C2114 NCB31HK-331X C CAPACITOR 330pF 50V K
C2115 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2116 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2129 NEAF1HM-475X E CAPACITOR 4.7uF 50V M
C2131 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2132 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2133 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2134 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2139 NEAF1EM-475X E CAPACITOR 4.7uF 25V M
C2140 NEAF1EM-475X E CAPACITOR 4.7uF 25V M
C2141 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2142 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2143 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2144 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2149 NEAF1EM-475X E CAPACITOR 4.7uF 25V M
C2150 NEAF1EM-475X E CAPACITOR 4.7uF 25V M
C2151 NEAF1AM-107X E CAPACITOR 100uF 10V M
C2152 NEAF1AM-107X E CAPACITOR 100uF 10V M
C2153 NEAF1CM-106X E CAPACITOR 10uF 16V M
C2154 NCF21CZ-155X C CAPACITOR 1.5uF 16V Z
C2155 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C2156 NCF21CZ-155X C CAPACITOR 1.5uF 16V Z
C2157 NCF21CZ-155X C CAPACITOR 1.5uF 16V Z
C2158 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2159 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C2160 NCF21CZ-155X C CAPACITOR 1.5uF 16V Z
C2161 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2162 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2163 NDC31HJ-181X C CAPACITOR 180pF 50V J
C2164 NDC31HJ-181X C CAPACITOR 180pF 50V J
C2165 NCB31CK-683X C CAPACITOR 0.068uF 16V K
C2166 NCB31CK-683X C CAPACITOR 0.068uF 16V K
C2167 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2168 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2201 NCB31HK-392X C CAPACITOR 3900pF 50V K
C2202 NCB31HK-392X C CAPACITOR 3900pF 50V K
C2209 NEAF1HM-225X E CAPACITOR 2.2uF 50V M
C2210 NEAF1HM-225X E CAPACITOR 2.2uF 50V M
C2229 NEAF1HM-105X E CAPACITOR 1uF 50V M
C2230 NEAF1HM-105X E CAPACITOR 1uF 50V M
C2241 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2242 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2243 NCB31HK-472X C CAPACITOR 4700pF 50V K
C2244 NCB31HK-472X C CAPACITOR 4700pF 50V K
C2245 NFV41HJ-122X MPPS CAPACITOR 1200pF 50V J
C2246 NFV41HJ-122X MPPS CAPACITOR 1200pF 50V J
C2247 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2248 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2249 NEAF1HM-225X E CAPACITOR 2.2uF 50V M
 Symbol No. Part No. Part Name Description Local
