JVC SP-PWM508 Service Manual

3-14
Electrical parts list
Main board
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
IC411 MM1233XF-X IC
IC431 MM1623XF-X IC
IC471 MN101C49GMY1 IC
IC472 S-80840CNNB-W IC
IC473 SN74HCT32NS-X IC(DIGITAL)
IC475 RC4580ID-X IC
IC476 RC4580ID-X IC
IC477 BR24L08F-W-X IC(DIGITAL)
IC478 RC4580ID-X IC
IC491 KIA7805API IC
IC601 RC4580ID-X IC
IC701 RC4580ID-X IC
IC761 BU9253FS-X IC
 IC901 STR-G6651 IC
IC951 PQ05RD21 IC
IC953 KIA7805API IC
Q951 2SC3576-JVC-T TRANSISTOR
Q953 KTA1267/YG/-T TRANSISTOR
Q954 SI2305DS-X TRANSISTOR
Q955 KRC103S-X DIGITAL TR
Q958 KTA1271/OY/-T TRANSISTOR
Q959 KRC103S-X DIGITAL TR
Q960 2SB709A/QR/-X TRANSISTOR
Q961 KTC3203/OY/-T TRANSISTOR
Q991 2SD601A/QR/-X TRANSISTOR
Q4091 KTA1271/OY/-T TRANSISTOR
Q4092 KTC3875/YG/-X SI TRANSISTOR
Q4701 KRC111S-X TRANSISTOR
Q4702 KRC107S-X DIGI TRANSISTOR
Q4703 KRC102S-X DIGI TRANSISTOR
Q4801 KTA1504/YG/-X SI TRANSISTOR
Q4802 KRC102S-X DIGI TRANSISTOR
Q4811 KRA102S-X DIGI TRANSISTOR
Q4812 KRC102S-X DIGI TRANSISTOR
Q4821 KRC102S-X DIGI TRANSISTOR
Q4831 KRC102S-X DIGI TRANSISTOR
Q4832 KRA110S-X TRANSISTOR
Q4833 KRC110S-X DIGI TRANSISTOR
Q4921 KTC3203/OY/-T TRANSISTOR
Q4931 KTA1271/OY/-T TRANSISTOR
Q4954 2SA1362/G/-X TRANSISTOR
Q4955 KRC102S-X DIGI TRANSISTOR
Q4961 KTC3203/OY/-T TRANSISTOR
Q4971 2SC3661-X TRANSISTOR
Q4972 2SC3661-X TRANSISTOR
Q4973 KRA104S-X DIGI TRANSISTOR
Q7301 KRC102S-X DIGI TRANSISTOR
Q7302 2SA1037AK/RS/-X TRANSISTOR
Q7401 2SC2412K/R/-X TRANSISTOR
Q7402 2SC2412K/R/-X TRANSISTOR
 D901 DI106 BRIDGE DIODE
D902 ERA18-04-T1 FR DIODE
D903 ERA18-04-T1 FR DIODE
D904 ERA18-04-T1 FR DIODE
D908 ERA18-04-T1 FR DIODE
D910 ERA18-04-T1 FR DIODE
D911 FR104S-T5 FR DIODE
D950 MTZJ30C-T2 Z DIODE
D951 FR104S-T5 FR DIODE
D952 FR104S-T5 FR DIODE
 D953 RK34-LFB2 FUSEIODE
 D954 FR104S-T5 FR DIODE
 D956 FR104S-T5 FR DIODE
 D957 FR104S-T5 FR DIODE
D958 1SS133-T2 DIODE
D960 MTZJ2.2A-T2 S.B.DIODE
 D970 ER204-F33 FR DIODE
D991 MTZJ5.1B-T2 Z DIODE
D4091 1SS133-T2 DIODE
D4092 MTZJ6.8A-T2 Z DIODE
D4703 MTZJ4.7B-T2 Z DIODE
D4704 1SS133-T2 DIODE
D4705 1SS133-T2 DIODE
D4706 1SS133-T2 DIODE
D4707 1SS133-T2 DIODE
D4708 1SS133-T2 DIODE
D4709 1SS133-T2 DIODE
D4811 1SS133-T2 DIODE
D4831 1SS133-T2 DIODE
D4832 1SS133-T2 DIODE
D4833 1SS133-T2 DIODE
D4834 1SS133-T2 DIODE
D4835 MTZJ6.8A-T2 Z DIODE
D4841 MTZJ2.0A-T2 Z DIODE
D4842 MTZJ3.3A-T2 Z DIODE
D4891 MTZJ6.2C-T2 Z DIODE
D4921 MTZJ8.2C-T2 Z DIODE
D4922 1SS133-T2 DIODE
D4931 MTZJ8.2C-T2 Z DIODE
D4932 1SS133-T2 DIODE
D4961 MTZJ4.7A-T2 Z DIODE
D4962 1SS133-T2 DIODE
D4963 1SS133-T2 DIODE
D7401 1SS355-X SI DIODE
D7402 1SS355-X SI DIODE
D7501 1SS355-X SI DIODE
 PC901 PC123Y22FZ PHOTO COUPLER
 PC902 PC123Y22FZ PHOTO COUPLER
 C902 QFZ9075-683 MPP CAPACITOR 0.068uF AC275V M
 C904 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C905 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C907 QETM2GM-107 E CAPACITOR 100uF 400V M
C908 QCZ0136-332Z C CAPACITOR 3300pF 1kV K
C909 QCZ0136-101Z C CAPACITOR 100pF 1kV K
C910 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C913 QCZ0136-101Z C CAPACITOR 100pF 1kV K
C914 QEZ0532-396Z E CAPACITOR 39uF 25V M
C915 QCBB1HK-471Y C CAPACITOR 470pF 50V K
 C916 QCZ9079-222 C CAPACITOR 2200pF AC250V M
C918 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C951 NDC31HJ-101X C CAPACITOR 100pF 50V J
C952 QCZ0136-101Z C CAPACITOR 100pF 1kV K
C953 NDC31HJ-101X C CAPACITOR 100pF 50V J
C954 NDC31HJ-101X C CAPACITOR 100pF 50V J
C956 NDC31HJ-101X C CAPACITOR 100pF 50V J
C957 NDC31HJ-101X C CAPACITOR 100pF 50V J
C960 QEZ0529-826Z E CAPACITOR 82uF 10V M
C961 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C962 QETN1HM-226Z E CAPACITOR 22uF 50V M
C963 QEZ0533-396Z E CAPACITOR 39uF 50V M
C964 QETN1HM-226Z E CAPACITOR 22uF 50V M
C965 QEZ0528-108 E CAPACITOR 1000uF 10V M
C966 QETN1AM-477Z E CAPACITOR 470uF 10V M
C967 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C968 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C969 QETN1AM-227Z E CAPACITOR 220uF 10V M
C976 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C977 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C978 QETN1AM-107Z E CAPACITOR 100uF 10V M
C979 QEZ0530-827 E CAPACITOR 820uF 16V M
C980 QETN1HM-106Z E CAPACITOR 10uF 50V M
C981 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C982 QEZ0531-567 E CAPACITOR 560uF 25V M
C984 QETN1CM-227Z E CAPACITOR 220uF 16V M
C985 QETN1EM-107Z E CAPACITOR 100uF 25V M
C986 QETN1EM-107Z E CAPACITOR 100uF 25V M
C987 QEZ0532-187Z E CAPACITOR 180uF 25V M
C989 QETN1CM-107Z E CAPACITOR 100uF 16V M
C992 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C993 NDC31HJ-101X C CAPACITOR 100pF 50V J
C994 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C997 QETN1CM-227Z E CAPACITOR 220uF 16V M
 Symbol No. Part No. Part Name Description Local
