JVC TH-A25 Service Manual

(No.MB141)1-17
5.1.3.2 In this case "LOW" for Base of Q13(A733) at Main PCB
5.1.3.3 Check the Connector Wire Ass'y Connectin of each PCB
Check the Turn on for channel of Q35(C945)
Check circuit for channel(Turn on)
according feedback "A"position of
previous page
;DVD MECHA - Main PCB (8P,PW3)
;POWER TRANS - Main PCB (ACW3)
