44
Specifications
Amplifier section—CA-UXG70
Output Power: 160 W (80 W+80 W) at 6
Ω
(10% THD)
Audio Input LINE IN:
500 mV/49 k
Ω
(at “L.IN LVL1”)
250 mV/49 k
Ω
(at “L.IN LVL2”)
125 mV/49 k
Ω
(at “L.IN LVL3”)
MIC:
1.6 mV/10 k
Ω
Audio Output LINE OUT:
1.0 Vrms (3 k
Ω)
(at “L.OUT LVL1”)
500 mVrms (1.5 k
Ω)
(at “L.OUT LVL2”)
SUBWOOFER OUT: 260 mVrms/3.9 k
Ω
HEADPHONES OUT: 17 mW/32
Ω
Digital output: DVD OPTICAL DIGITAL OUT:
–21 dBm to –15 dBm (660 nm ±30 nm)
USB input: USB AUDIO
Video output:
Color system: NTSC or PAL(interlaced/progressive)
VIDEO (composite): 1 V(p-p)/75
Ω
S-VIDEO:Y (luminance) 1 V(p-p)/75
Ω
C (chrominance, burst)
NTSC 0.286 V(p-p)/75
Ω
PAL 0.3 V(p-p)/75
Ω
COMPONENT: (Y) 1 V(p-p)/75
Ω
(P
B
/P
R
) 0.7 V(p-p)/75
Ω
Speaker impedance: 6
Ω
– 16
Ω
Headphone impedance: 16
Ω
– 1 k
Ω
Tuner section
FM tuning range: 87.5 MHz – 108.0 MHz
AM (MW) tuning range:
531 kHz – 1 710 kHz (at 9 kHz intervals)
530 kHz – 1 710 kHz (at 10 kHz intervals)
For Saudi Arabia only:
531 kHz – 1 602 kHz (at 9 kHz intervals)
530 kHz – 1 600 kHz (at 10 kHz intervals)
Tape section
Frequency response: 60 Hz – 14 000 Hz
Wow and flutter: 0.15 % (WRMS)
Disc player section
Region codes: Middle East: 2
South East Asia: 3
Playable disc: DVD Video/DVD Audio/CD/VCD/SVCD
CD-R/CD-RW (CD/SVCD/VCD/MP3/
WMA/JPEG/MPEG-1/MPEG-2/ASF/DivX
format)
DVD-R/-RW (DVD-VR/DVD Video/MP3/
WMA/JPEG/MPEG-1/MPEG-2/ASF/DivX
format)
+R/+RW(DVD Video format)
DVD-ROM (DVD Video format)
Dynamic range: 80 dB
Horizontal resolution: 500 lines
Wow and flutter: Immeasurable
General
Power requirement:
AC 110 V/AC 127 V/AC 220 V/ AC 230 V-240 V
(adjustable with the voltage selector), 50 Hz/60 Hz
Power consumption: 95 W (at operation)
18 W (at standby)
3.9 W (at standby display OFF mode)
Dimensions (approx.): 175 mm x 250 mm x 411 mm
(W/H/D)
Mass (approx.): 7.9 kg
Speakers—SP-UXG70
Speaker units: Tweeter: 1.5 cm dome x 1
Squawker: 4 cm cone x 1
Woofer: 13.5 cm cone x 1
Impedance: 6
Ω
Dimensions (approx.): 166 mm x 250 mm x 232 mm
(W/H/D)
Mass (approx.): 2.8 kg each
Supplied Accessories
See page 3.
Design and specifications are subject to change without
notice.
• Manufactured under license from Dolby Laboratories. “Dolby”,
“Pro Logic”, “MLP lossless”, and the double-D symbol are
trademarks of Dolby Laboratories.
• “DTS” and “DTS 2.0+ Digital Out” are registered trademarks of
Digital Theater Systems, Inc.
• “Official DivX
®
Certified product” “Plays all versions of DivX
®
video (including DivX
®
6) with standard playback of DivX
®
media files” “DivX, DivX certified, and associated logos are
trademarks of DivX, Inc. and are used under licence.”
• USE OF THIS PRODUCT IN ANY MANNER THAT
COMPLIES WITH THE MPEG-4 VISUAL STANDARD IS
PROHIBITED, EXCEPT FOR USE BY A CONSUMER
ENGAGING IN PERSONAL AND NON-COMMERCIAL
ACTIVITIES.
• This product incorporates copyright protection technology that is
protected by U.S. patents and other intellectual property rights.
Use of this copyright protection technology must be authorized by
Macrovision, and is intended for home and other limited viewing
uses only unless otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.
“CONSUMERS SHOULD NOTE THAT NOT ALL HIGH
DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE
WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE
DISPLAYED IN THE PICTURE. IN CASE OF 525 OR 625
PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS
RECOMMENDED THAT THE USER SWITCH THE
CONNECTION TO THE ‘STANDARD DEFINITION’ OUTPUT.
IF THERE ARE QUESTIONS REGARDING OUR TV SET
COMPATIBILITY WITH THIS MODEL 525p AND 625p DVD
PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE
CENTER.”
UX-G70[U].book Page 44 Monday, April 17, 2006 5:18 PM
