JVC UX-V30 User Manual

UX-V30
3-10
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
C 901 QFLK1HJ-104Z TF CAPACITOR .10MF 5% 50V
C 902 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C 903 QFLK1HJ-104Z TF CAPACITOR .10MF 5% 50V
C 904 QFLK1HJ-104Z MF CAPACITOR .10MF 5% 50V
C 906 QFLM1HJ-104Z MF CAPACITOR .10MF 5% 50V
CN301 QGB1214J1-20S CONNECTOR MICON
CN302 QGB1214J1-14S CONNECTOR MICON
CN303 QGF1205C1-10 CONNECTOR CD
CN304 QGF1205F1-09 CONNECTOR SLC
CN305 QGF1205F1-10 CONNECTOR SLC
CN306 QGA2501C1-05 5P CONNECTOR HEADPHONE
CN307 QGA2501C1-02 2P CONNECTOR CD DOOR
CN309 QGA2501F1-03 CONNECTOR OPTICAL
CN901 QGA7901C1-02 CONNECTOR
A
CN902 QGA3901C1-03 3P CONNECTOR
C1101 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C1102 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V
C1103 QFLM1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1104 QTE1V06-106Z E CAPACITOR
C1150 QDGB1HK-102Y C CAPACITOR
C1300 QFLM1HJ-823Z M CAPACITOR .082MF 5% 50V
C1301 QFLM1HJ-823Z M CAPACITOR .082MF 5% 50V
C1302 QTE1C06-226Z E CAPACITOR
C1303 QFVJ1HJ-274Z MF CAPACITOR .33MF 5% 50V
C1500 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C1501 QFLM1HJ-272Z M CAPACITOR 3900PF 5% 50V
C1502 EETC1HM-475ZJC E CAPACITOR 4.7MF 20% 50V
C1503 QTE1V06-106Z E CAPACITOR
C1504 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1505 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1506 QFLM1HJ-272Z M CAPACITOR 2700PF 5% 50V
C1507 EETC1HM-475ZJC E CAPACITOR 4.7MF 20% 50V
C1508 EETC1HM-475ZJC E.CAPA. I.M
C1510 QETN1EM-475Z E CAPACITOR 4.7MF 20% 25V
C1600 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C1700 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C1800 QETN1EM-475Z E CAPACITOR 4.7MF 20% 25V
C2101 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C2102 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V
C2103 QFLM1HJ-104Z MF CAPACITOR .10MF 5% 50V
C2104 QTE1V06-106Z E CAPACITOR
C2150 QDGB1HK-102Y C CAPACITOR
C2300 QFLM1HJ-823Z M CAPACITOR .082MF 5% 50V
C2301 QFLM1HJ-823Z M CAPACITOR .082MF 5% 50V
C2302 QTE1C06-226Z E CAPACITOR
C2303 QFVJ1HJ-274Z MF CAPACITOR .27MF 5% 50V
C2500 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C2501 QFLM1HJ-272Z M CAPACITOR 3900PF 5% 50V
C2502 EETC1HM-475ZJC E CAPACITOR 4.7MF 20% 50V
C2503 QTE1V06-106Z E CAPACITOR
C2504 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C2505 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C2506 QFLM1HJ-272Z M CAPACITOR 2700PF 5% 50V
C2507 EETC1HM-475ZJC E CAPACITOR 4.7MF 20% 50V
C2508 EETC1HM-475ZJC E.CAPA. I.M
C2510 QETN1EM-475Z E CAPACITOR 4.7MF 20% 25V
C2600 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C2700 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C2800 QETN1EM-475Z E CAPACITOR 4.7MF 20% 25V
C3100 QETM1EM-828 E CAPACITOR
A
8200MF 20% 25V
C3101 QFLM1HJ-104Z MF CAPACITOR .10MF 5% 50V
C3102 EEKC1AM-107ZJC E CAPACITOR
C3103 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C3104 QETC1AM-336Z E CAPACITOR 33MF 20% 10V
C3105 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C3150 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C3300 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C3301 QETN1AM-476Z E CAPACITOR 47MF 20% 10V
C3400 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C3401 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C3402 QFLC1HJ-563Z TF CAPACITOR .056MF 5% 50V
C3403 QFLC1HJ-563Z TF CAPACITOR .056MF 5% 50V
C3404 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C3405 QETN1CM-106Z E CAPACITOR 10MF 20% 16V
C3406 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C3500 QETN1CM-107Z E.CAPACITOR 100MF 20% 16V
C3501 QETN1EM-106Z E.CAPACITOR 10MF 20% 25V
C3502 QDYB1CM-103Y C.CAPACITOR
C3504 QDGB1HK-102Y C CAPACITOR
C3505 QDGB1HK-102Y C CAPACITOR
C3506 QDGB1HK-102Y C CAPACITOR
C3507 QDGB1HK-102Y C CAPACITOR
C3700 QETN1HM-684Z E CAPACITOR .68MF 20% 50V
C3800 EETC1HM-105ZJC E.CAPA. I.M
C9001 EETC1CM-227ZJC E CAPACITOR 22MF 20% 16V
C9002 QDYB1CM-103Y C.CAPACITOR
C9003 QDXB1CM-222Y C.CAPA IM
C9201 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C9202 QDYB1CM-103Y C.CAPACITOR
C9203 QTE1V06-106Z E CAPACITOR 10MF 20% 16V
C9302 QEKC1HM-475Z E.CAPACITOR 4.7MF 20% 50V
C9303 QEKC1AM-107Z E.CAPACITOR 100MF 20% 10V
C9401 EEKC1AM-227ZJC E CAPACITOR 220MF 20% 10V
C9402 EEKC1AM-107ZJC E CAPACITOR
C9403 QDYB1CM-103Y C.CAPACITOR
C9501 EETC1AM-477ZJC E CAPACITOR 470MF 20% 10V
C9502 QEKC1AM-476Z E.CAPACITOR 47MF 20% 10V
C9600 QDYB1CM-103Y C.CAPACITOR
C9601 EETC1HM-107ZJC E CAPACITOR
C9602 EETC1HM-106ZJC E CAPACITOR 10MF 20% 50V
C9603 EETC1HM-106ZJC E.CAPA. I.M
D 901 6A10E2 SI DIODE
A
D 902 6A10E2 SI DIODE
A
D 903 6A10E2 SI DIODE
A
D 904 6A10E2 SI DIODE
A
D 906 1SR35-400A-T5 DIODE I/M
D3300 MTZJ4.3B-T2 ZENER DIODE
D3400 1SS133-T2 SI DIODE
D3401 1SS133-T2 SI DIODE
D3402 1SS133-T2 SI DIODE
D3403 1SS133-T2 SI DIODE
D3504 1SS133-T2 SI DIODE
D3505 1SS133-T2 SI DIODE
D3800 MTZJ6.8B-T2 ZENER DIODE
D9001 1SS133-T2 SI DIODE
D9002 MTZJ8.2C-T2 ZENER DIODE
D9003 MTZJ10A-T2 ZENER DIODE
D9101 1SR35-400A-T5 SI.DIODE
D9201 MTZJ5.1C-T2 ZENER DIODE
D9301 MTZJ3.9B-T2 Z DIODE IM
D9302 1SS133-T2 SI DIODE
D9303 1SS133-T2 SI DIODE
D9402 MTZJ6.2A-T2 Z.DIODE IDM
D9501 1SS133-T2 SI DIODE
D9502 1SS133-T2 SI DIODE
D9503 MTZJ5.1B-T2 ZENER DIODE
(Main board)
Item
Parts number Parts name Area
Remarks
A
