Operating Manual HDS Standard 9.808-214.0
7
PRESSURE WASHER
OPERATOR’S MANUAL
COMPONENT IDENTIFICATION
High Pressure
Nozzle
Hose Reel Mount Adapter
(not included, sold
separately)
Hose Reel Mount Support
Accessory Storage
Filling Opening
For RM110
(Not HDS 2.2/12 Ed)
Detergent Hose
With Filter
Detergent
Regulating valve
Unloader
Water Inlet
Filter
Spray Lance
EASY!Lock
Diesel Tank
Filling Neck
Caster With
Brake
12” Non Flat
Wheels
Water Inlet
Connection
Burner Chimney
Exhaust
Crane Lifting
Point
High Pressure
Hose EASY!Lock
Support For
Spray Lance
Trigger Gun
EASY!Force
Control
Panel
Fuel Tank
Cover
High Pressure
Discharge Port
EASY!Lock Connection
Handle
Power cord
with GFCI
(Not HDS 2.2/12 Ed)
