Kärcher BD 38/12 C Bp User Manual

– 15
Technical specifications
Power
Nominal voltage V 25,2
Battery capacity Ah (5h) 21
Battery type Li-ion
Average power consumption W 500
Suction engine output W 280
Brush engine output W 260
Operating temperature range °C 0...40
Vacuuming
Cleaning power, air quantity l/s 20
Cleaning power, negative pressure kPa 8
Cleaning brushes
Working width mm 380
Brush diameter mm 380
Brush speed 1/min 180
Charger
Voltage V/Hz 110-120 / 50/60
Power consumption A 4
Dimensions and weights
Theoretical surface cleaning performance m
2
/h 1400
Fresh/waste water tank volume l 12
Permissible overall weight kg 48
Transport weight kg 36
Length x width x height mm 940x500x1100
Values determined as per EN 60335-2-72
Total oscillation value m/s
2
<2,5
Uncertainty K m/s
2
0,2
Sound pressure level L
pA
dB(A) 65
Uncertainty K
pA
dB(A) 2
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 85
17EN

Kärcher BD 38/12 C Bp Specifications

General

Maximum input power	500 W
Maximum area performance	1500 m²/h
Waste container capacity	1 L
Fresh water tank capacity	12 L
Brush rotation speed (min)	180 RPM
Practical area performance	1050 m²/h
Battery voltage	25.2 V
Battery capacity	21 Ah

Weight and Dimensions

Depth	500 mm
Width	940 mm
Height	1100 mm
Weight (including battery)	36000 g
