Specifications
BPE 4200/50 BPE 5000/55
Voltage V 230 - 240 230 - 240
Frequency Hz 50 50
Output P
nom
W 1100 1300
Max. flow rate* l/h 4200 4800
Max. Suction height m 9 9
Max. pressure MPa
(bar)
0,49
(4,9)
0,55
(5,5)
Pressure at switch-on MPa
(bar)
0,16
(1,6)
0,16
(1,6)
Overpump time setting s 3/5/10/20/30 3/5/10/20/30
Cut off value / flow l/h < 200 < 200
Max. flow height m 49 55
Max. grain size of the dirt particles that
can be transported
mm 1 1
Weight kg 10,3 11,9
LED class 1 as per EN 60825-1
Subject to technical modifications!
*The max. flow rate is derived from the measurement without the backflow valve in-
stalled.
The possible flow rate is even larger:
- the lower the flow heights are
- the larger the diameter of the hoses used are
- the shorter the hoses used are.
