Kärcher HD 5/15 CX User Manual

– 9
Technical specifications
Type HD 5/15 C
HD 5/15 CX
HD 6/13 C
HD 6/13 CX
Main Supply
Voltage V 230
Current type Hz 1~ 50
Connected load kW 2,7
Protection (slow, char. C) A 16
Maximum allowed net impedance Ohm 0.2679 0.346+j.216
Extension cord 30 m mm
2
2,5
Water connection
Max. feed temperature °C 60
Min. feed volume l/h (l/min) 700 (11,7)
Suck height from open container (20 °C) m 0,5
Max. feed pressure MPa (bar) 1 (10)
Performance data
Working pressure MPa (bar) 15 (150) 13 (130)
Max. operating over-pressure MPa (bar) 18,5 (185) 17 (170)
Flow rate l/h (l/min) 500 (8,3) 560 (9,3)
Detergent suck in l/h (l/min) 0...35 (0...0,6)
Max. recoil force of hand spray gun N 25
Nozzle size (CX) -- 031 (032) 038
Values determined as per EN 60355-2-79
Noise emission
Sound pressure level L
pA
dB(A) 75
Uncertainty K
pA
dB(A) 2
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 91
Hand-arm vibration value
Hand spraygun m/s
2
2,7
Spray lance m/s
2
<2,5
Uncertainty K m/s
2
1
Fuel
Amount of oil l 0,38
Oil grade -- SAE 15W40
Dimensions and weights
Length mm 360
Width (CX) mm 375 (400)
Height mm 925
Weight without accessories (CX) kg 23 (28)
23EN

Kärcher HD 5/15 CX Specifications

General

Pressure	150 bar
Flow rate	500 l/h
Power	2.8 kW
Voltage	230 V
Frequency	50 Hz
Hose length	15 m
