Kärcher K 3.81 M User Manual

6 English
" STEP 1: Mount transport handle.
" STEP 2: Attach the high pressure
hose to the trigger gun.
Pull out the locking slide from the
right side of the trigger gun handle
(A), and insert the small end of the
high pressure hose into place (B).
Push the locking slide back into the
trigger gun (C) to lock the hose in po-
sition (D).
ASSEMBLY INSTRUCTIONS

Kärcher K 3.81 M Specifications

General

Brand	Kärcher
Model	K 3.81 M
Category	Pressure Washer
Language	English
