Kärcher Puzzi 10/1 User Manual

– 7
Technical specifications
Puzzi 10/1 Puzzi 10/2 Adv
Mains voltage V 120 120
Frequency Hz 1~ 60 1~ 60
Type of protection -- IPX4 IPX4
Protective class II II
Rated current A 9 9
Air volume (max.) CFM (l/s) 114 (54) 114 (54)
Negative pressure (max.) mm (kPa) 2240 (22.0) 2240 (22.0)
Spray pump performance W 40 80
Spray pressure psi (MPa) 14.5 (0.1) 29.0 (0.2)
Spray pressure (max.) psi (MPa) 43.5 (0.3) 43.5 (0.3)
Spray volume gal/min (l/min) 0.26 (1) 0.53 (2)
Temperature of the cleaning solution
(max.)
°F (°C) 122 (+50) 122 (+50)
Filling quantity of fresh water gal (l) 2.6 (10) 2.6 (10)
Fill volume wastewater gal (l) 2.4 (9) 2.4 (9)
Length x width x height in (mm) 27.8 x 12.5 x 17.0
(705 x 320 x 435)
27.8 x 12.5 x 17.0
(705 x 320 x 435)
Typical operating weight lbs (kg) 23.6 (10.7) 25.1 (11.4)
Max. ambient temperature °F (°C) 104 (+40) 104 (+40)
Values determined to EN 60335-2-68
Sound pressure level L
pA
dB(A) 73 73
Uncertainty K
pA
dB(A) 1 1
Power cord SJTW 2/16 AWG
Part no.: Cable length
CUL 6.647-967.0 25 ft (7.5 m)
12 EN

Kärcher Puzzi 10/1 Specifications

General

Maximum input power	1250 W
Annual energy consumption	- kWh
Type	Drum vacuum
Cleaning type	Wet
Dust capacity	- L
Product color	Black, Yellow
Tube material	The material the tube is made of.
Dust container type	-
Proper use	Professional
Noise level	- dB
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	Water

Weight and Dimensions

Depth	705 mm
Width	320 mm
Height	435 mm
Weight	10700 g
