Kärcher Puzzi 10/1 User Manual

– 3
Note: Warm water (max. 122°F/50°C) will
increase the cleaning effect. Verify the tem-
perature resistance of the surface to be
cleaned.
Note: For considerate treatment of the en-
vironment use detergent economically.
 Fill detergent solution into the fresh wa-
ter reservoir. The fill level must not ex-
ceed the "MAX" mark.
Note: When cleaning previously sham-
pooed carpets, foam is generated in the
wastewater container. This formation of
foam can be prevented by adding a de-
foaming agent.
Puzzi 10/1 only:
 Put defoaming agent (optional accesso-
ry) into the wastewater container.
Puzzi 10/2 Adv only:
 Open container for defoaming agent.
 Fill in defoaming agent (optional acces-
sory).
 Push the unlocking device of the floor
nozzle on one side.
 Swivel out and remove the carpet
adapter.
 Insert a new carpet adapter and snap
the locking device in place.
 Plug in the main plug.
 Press the suction switch to turn on the
suction turbine.
 Press the spray switch to switch on the
spray pump.
Caution
Risk of damage. Check the object to be
cleaned prior to using the appliance in an
inconspicuous place for colour fastness
and water resistance.
 Operate the lever on the manifold in or-
der to spray the cleaning solution.
 Run across the surface to be cleaned in
overlapping paths. Pull the nozzle back-
wards (do not push).
 In case of work interruptions, the floor
nozzle can be stored in the handle.
 Switch off the spray and suction switches.
 Pull out the mains plug.
 If the dirt water reservoir is full, switch
off the suction and spray switches.
 Remove the lid.
 Remove the wastewater container from
the appliance and drain it.
 Turn off the appliance.
 Shortly activate the lever on bender to
decrease the pressure.
 Separate bender from the spray/suction
hose.
 Insert the suction hose into the fresh
water reservoir.
 Press the suction switch to turn on the
suction turbine.
 Empty the fresh water reservoir and
switch the appliance off.
 Remove the lid.
 Remove the wastewater container from
the appliance and drain it.
 Connect the manifold (with suction pipe
and nozzle) to the suction hose.
 Connect the coupling of the spray hose
with the manifold and snap in place.
 Fill approx. 0.5 gal (2 litres) of fresh wa-
ter into the fresh water reservoir.
Do not add any detergents.
 Press the spray switch to switch on the
spray pump.
 Hold floor nozzle over a drain.
 Activate lever on bender and flush the
appliance for appr. 1 to 2 minutes.
 Turn off the appliance.
Fill up fresh water reservoir
Defoaming agent
Replacing the carpet adapter
Operation
Turning on the Appliance
Cleaning
Turn off the appliance
Empty wastewater container
Empty the fresh water reservoir
Flush appliance
8 EN

Kärcher Puzzi 10/1 Specifications

General

Maximum input power	1250 W
Annual energy consumption	- kWh
Type	Drum vacuum
Cleaning type	Wet
Dust capacity	- L
Product color	Black, Yellow
Tube material	The material the tube is made of.
Dust container type	-
Proper use	Professional
Noise level	- dB
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	Water

Weight and Dimensions

Depth	705 mm
Width	320 mm
Height	435 mm
Weight	10700 g
