Kärcher Puzzi 10/1 User Manual

– 4
 Flush appliance.
 Empty the wastewater container and
clean it under running water.
 Empty the fresh water reservoir.
 Clean the outside of the appliance with
a damp cloth.
 Remove all water from the appliance
prior to longer periods of non-use to
avoid offensive odours.
 Allow appliance to dry thoroughly: Re-
move or move lid sideways.
 Place the appliance in a dry room and
secure it from unauthorized use.
 Spray and suction off detergent solution
in one work cycle.
Note: Repeated suctioning without spray-
ing will shorten the drying time.
 Apply detergent solution with suction
turbine turned off and soak for 10 to 15
minutes.
 Clean the surface just like with normal
soiling.
 In order to further improve the cleaning
result, the surface can be recleaned us-
ing clear, warm water.
 Puzzi 10/1 only:
Attach hand nozzle instead of the floor
nozzle.
 With sensitive materials, use less deter-
gent and spray the surface at a distance
of approx. 7.9 in (200 mm). Then simply
vacuum off.
– Highly soiled spots should be pre-
soaked and the detergent solution
should soak 5 to 10 minutes.
– Always work from the light to the shade
(from the window to the door).
– Always work from the cleaned to the un-
cleaned surface.
– The more sensitive the surface (oriental
rugs, berbers, upholstery material) the
lower the cleaning solution concentra-
tion should be.
– Rugs with jute backing can shrink if too
much water is used and can bleed col-
ours.
– Brush high-fiber rugs in the direction of
the weave after cleaning (using a fiber
brush or a scrubber).
– Water-proofing the fabric using Care
Tex RM 762 after the wet cleaning pre-
vents a quick resoiling of the textile sur-
face.
– Do not step on cleaned surfaces until
they have dried and do not place furni-
ture on them to avoid pressure spots or
rust stains.
For further information, please request
product information sheet and EU safety
data sheet of the relevant detergent.
Caution
Risk of injury and damage! Observe the
weight of the appliance when you transport
it.
Illustration
 For transport, place suction pipe on the
carrying handle and place the spray/
suction hose on top of the appliance.
Wind up the mains cable and hook it
into the cable hook.
 When transporting in vehicles, secure
the appliance according to the guide-
lines from slipping and tipping over.
After each operation
Storing the Appliance
Cleaning methods
Normal soiling
Strong soiling or stains
Upholstery cleaning
Cleaning tips
Detergent
Carpet and upholstery
cleaning
RM 760 powder
RM 760 tabs
RM 764 liquid
Defoaming RM 761
Waterproofing carpets RM 762
Transport
9EN

Kärcher Puzzi 10/1 Specifications

General

Maximum input power	1250 W
Annual energy consumption	- kWh
Type	Drum vacuum
Cleaning type	Wet
Dust capacity	- L
Product color	Black, Yellow
Tube material	The material the tube is made of.
Dust container type	-
Proper use	Professional
Noise level	- dB
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	Water

Weight and Dimensions

Depth	705 mm
Width	320 mm
Height	435 mm
Weight	10700 g
