Keithley 2002 Calibration Manual

3
Calibration Command Reference
3-1
3.1 Introduction
This section contains detailed information on the various
Model 2002 IEEE-488 bus calibration commands. Section 2
of this manual covers detailed calibration procedures, and
Appendix B lists calibration programs. For information on
additional commands to control other instrument functions,
refer to the Model 2002 User's Manual.
Information in this section includes:
3.2 Command summary: Summarizes all commands
necessary to perform comprehensive, AC, and low-
level calibration.
3.3 CALibration:PROTected Subsystem: Gives detailed
explanations of the various commands used for both
comprehensive and low-level calibration.
3.4 CALibration:UNPRotected Subsystem: Discusses
the :ACC command, which is used to perform AC user
calibration over the bus.
3.5 Bus error reporting: Summarizes bus calibration
errors, and discusses how to obtain error information.
3.6 Detecting calibration step completion: Covers how
to determine when each calibration step is completed
by using the *OPC and *OPC? commands.
3.2 Commands
3.2.1 Command summary
Table 3-1 summarizes Model 2002 calibration commands
along with the paragraph number where a detailed descrip-
tion of each command is located.

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
