5½ Digit Multimeter Calibration Manual Section 2:
2110-905-01 Rev. C / August 2013 2-5
26. Set the Model 5700A output mode to STANDBY.
27. Configure the Model 2110 for the 100 V range by sending the following command:
CONF:VOLT:AC 100
28. Set the Model 5700A to 10 V and the output mode to OPERATE.
29. Adjust to 10 percent of range by sending the following command:
CAL:PROT:AC:STEP 1,10
30. Wait until the following message is displayed on the Model 2110:
Cali OK
31. Set the Model 5700A output to 100 V.
32. Adjust full scale measurement by sending the following command:
CAL:PROT:AC:STEP 2,100
33. Wait until the following message is displayed on the Model 2110:
Cali OK
34. Set the Model 5700A output mode to STANDBY.
35. Configure the Model 2110 for the 750 V range by sending the following command:
CONF:VOLT:AC 750
36. Set the Model 5700A to 75 V and the output mode to OPERATE.
37. Adjust to 10 percent of range by sending the following command:
CAL:PROT:AC:STEP 1,75
38. Wait until the following message is displayed on the Model 2110:
Cali OK
39. Set the Model 5700A output to 750 V.
40. Adjust full scale measurement by sending the following command:
CAL:PROT:AC:STEP 2,750
41. Wait until the following message is displayed on the Model 2110:
Cali OK
42. Set the Model 5700A output mode to STANDBY. Press RESET on the Model 5700A front panel
to reset the calibrator to its default settings.
Frequency range adjustment
1. Set the Model 5520A/5522A to 1 VAC 1 kHz: output to STANDBY mode.
2. Using shielded, low thermal EMF cables, connect the Fluke 5520A/5522A output HI and LO to
the Model 2110 input HI and LO terminals. Allow connections to stabilize for a minimum of five
minutes before proceeding.
3. Configure the Model 2110 for the 1 kHz range by sending the following command:
CONF:FREQ
4. Configure the Model 2110 for 1 V range and an aperture of 1 by sending the following
commands.
FREQ:VOLT:RANGE 1
FREQ:APER 1
